Overview
- Frequency Range: 405-440 MHz
- Gain: 5 dBi
- Polarization: Vertical/Horizontal
- Connector Types: N-, TNC-, 7/16-female
- VSWR: <1.5
- Radiator Material: Copper
- Mounting Diameter: 35-60 mm pole
Specifications
Connection Type | N-/TNC-/7/16-female |
Connector | N-/TNC-/7/16-female |
Frequency | 405-440 MHz |
Gain | 5 dBi |
Length | 285 mm |
Material | ABS/FG PU foam, copper |
Mounting Diameter | Ø 35-60 |
Mounting Type | 35-60 mm diameter pole |
Polarization | vertical/horizontal |
Radiator Material | copper |
Radome | ABS/FG, PU foam |
Series | CA420D |
VSWR | <1.5 |
Weight | 675 g |
Wind Load | 33 N @ 150 km/h |

CA400D
offset pattern dipole - Frequency range: 380-410 MHz - Gain: 5 dBi - Polarization: vertical/horizontal - Connector: N-/ TNC-/ 7/16-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 34 N
CA85D
offset pattern dipole - Frequency range: 83-88 MHz - Gain: 5 dBi - Polarization: vertical/horizontal - Connector: N-/ TNC-/ 7/16-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 84 N
CA860D
offset pattern dipole - Frequency range: 830-890 MHz - Gain: 5 dBi - Polarization: vertical/horizontal - Connector: N-/ TNC-/ 7/16-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 25 N
CA380D
offset pattern dipole - Frequency range: 365-395 MHz - Gain: 5 dBi - Polarization: vertical/horizontal - Connector: N-/ TNC-/ 7/16-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 35 N
CA350D
offset pattern dipole - Frequency range: 336-364 MHz - Gain: 5 dBi - Polarization: vertical/horizontal - Connector: N-/ TNC-/ 7/16-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 36 N
CA930D
offset pattern dipole - Frequency range: 880-960 MHz - Gain: 5 dBi - Polarization: vertical/horizontal - Connector: N-/ TNC-/ 7/16-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 25 N
CA450C2
offset pattern collinear - Frequency range: 440-475 MHz - Gain: 8 dBi - Polarization: vertical - Connector: N-/TNC-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 64 N
CA230C2
offset pattern collinear - Frequency range: 221-239 MHz - Gain: 8 dBi - Polarization: vertical - Connector: N-/TNC-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 90 N
CA170C2
offset pattern collinear - Frequency range: 163-177 MHz - Gain: 8 dBi - Polarization: vertical - Connector: N-/TNC-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 110 N
CA400C2
offset pattern collinear - Frequency range: 380-410 MHz - Gain: 8 dBi - Polarization: vertical - Connector: N-/TNC-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 68 N
CA350C2
offset pattern collinear - Frequency range: 336-364 MHz - Gain: 8 dBi - Polarization: vertical - Connector: N-/TNC-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 72 N
CA340C2
offset pattern collinear - Frequency range: 326-353 MHz - Gain: 8 dBi - Polarization: vertical - Connector: N-/TNC-female - VSWR: <1.5 - Radome: ABS/FG PU foam - Radiator material: copper - Mounting: 35-60 mm diameter pole - Wind load: 72 NHow to Install the CA420D Controller
