UPC: 783786277834
Documents & Media
Contact for Pricing
Overview
- 35kV voltage class with 21.1kV max phase-to-ground operating voltage
- 600A continuous current rating, 25kA symmetrical momentary withstand
- Meets ANSI/IEEE Standard 386 for deadbreak vault applications
- Aluminum construction for durability in underground environments
- Designed for de-energized connections using standard hand tools
Specifications
Application | 35kV, 600 Amps |
Connection Type | Threaded Stud |
Current Rating | 600 A |
Material | Metal |
Material | Tin Plated Aluminum |
Mounting Type | Vault Stretcher |
Series | 600 Series |
Size | 2.38 inch long |
Size | 35kV 600 Series |
Special Features | 5/8-11 UNC-2A Thread on both ends |
Type | Threaded Stud Connector |
Voltage Rating | 35 kV |
Voltage Rating | 35kV |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 1.0000 L |
Package Weight (Metric) | 0.4540 kg |
755LINK-BLRP0380ADRG
600 Amp, 35KV, Cam-Op Kit, Cable Insulation Diameter 1.725 inch to 1.935 inch. Aluminum Compression Lug. Conductor Size AWG or kcmil, Compressed Stranded 700/750 /Compacted Solid 900.650VSA
15/25kV 600 Amp Series Elbow Deadbreak Connector, Vault Stretcher Threaded Stud, 2.78 inches (70.6 mm) long, 5/8 - 11 UNC-2A Thread on Both Ends.
K1601WJ3-5
15/25kV 200 Amp, loadbreak 3-way Well Junction with U Straps, Hardware package consists of U Straps and back plate only.
K1601WJ2-5
15/25kV 200 Amp, loadbreak 2-way Well Junction with U Straps, Hardware package consists of U Straps and back plate only.
Frequently Asked Questions
How do I order the 35 kV Vault Stretcher Threaded Stud?
To order the 35 kV Vault Stretcher Threaded Stud, specify the product code 750VSA.
What material is the 750VSA Vault Stretcher Stud made from?
The 750VSA Vault Stretcher Threaded Stud is made from aluminum.
What is the voltage rating for the 750VSA?
The 750VSA threaded stud is designed for 35 kV applications.
What is the current rating of the 750VSA stud?
The 750VSA threaded vault stretcher stud has a current rating of 600A.
What is the full product name for 750VSA?
The 750VSA is a 35 kV Vault Stretcher Threaded Stud, also identified as PSS-750VSA.
What is the full product name for 750VSA?
The 750VSA is a 35 kV Vault Stretcher Threaded Stud, also identified as PSS-750VSA.
How do I order the 35 kV Vault Stretcher Threaded Stud?
To order the 35 kV Vault Stretcher Threaded Stud, specify the product code 750VSA.
What material is the 750VSA Vault Stretcher Stud made from?
The 750VSA Vault Stretcher Threaded Stud is made from aluminum.
What is the voltage rating for the 750VSA?
The 750VSA threaded stud is designed for 35 kV applications.
What is the current rating of the 750VSA stud?
The 750VSA threaded vault stretcher stud has a current rating of 600A.
