Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- Copper construction for high conductivity and corrosion resistance
- Supports 8 AWG wire with 2P+G (two poles plus ground) configuration
- Body size 1 for compatibility with standard motor control panels
- Red body color for easy identification in wiring systems
- Pigtail design simplifies installation and maintenance
Specifications
Color | Red |
Connection Type | Motor Pigtail Disconnect |
Finish | Tin Plated |
Material | Copper |
Poles | 2P |
Series | KUBE |
Size | Size 1 |
Special Features | Fast, snap-together assembly offers maximum labor savings. Not need for nuts, bolts and washers or insulating tape - simply slide on reusable boot |
Standard | UL E9809 |
Standard | UL E9809 / UL E9809 |
Type | Motor Lead Male Disconnect |
Voltage Rating | 600 V |
Package Dimensions (L x W x H) | 2.09 IN x 1.2 IN x 2.9 IN |
Package Dimensions (L x W x H) | 5.3086 cm x 3.048 cm x 7.366 cm |
Package Weight (Imperial) | 0.040 L |
Package Weight (Metric) | 0.018 kg |
M2D8M-2
KUBE Male (Two Load) Copper Motor Pigtail Disconnect, Wire Size 8 AWG, Body Size 2, Die Color Red
M2D1M-3
KUBE Male (Two Load) Copper Motor Pigtail Disconnect, Wire Size 1 AWG, Body Size 3, Die Color Green
MDBOOT-3
KUBE 600kV Insulator Boot for Disconnect Series MD-M and MD-F, Insulates Body Size 3, Black Thermoplastic Rubber
MDPWK23
Connector Kit Case Containing a Selection of Size 2 and 3 Male and Female Motor Disconnects Plus Insulators, 12 AWG - 4/0 AWGHow to Install the M2D8M-1 Controller
This guide provides step-by-step instructions for installing and configuring the M2D8M-1 Controller, including wiring and calibration.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Cable ties
- Mount the controller
Secure the M2D8M-1 Controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Strip and connect wires
Strip the ends of the wires to the appropriate length and attach them to the male and female motor disconnects as specified in the installation instructions.
- Crimp connectors
Use a compatible crimping tool to crimp the connectors securely onto the wires, ensuring a solid electrical connection.
- Insert connectors
Push the male pin into the female barrel until fully inserted, creating a secure connection.
- Install boot/insulator
Slide the boot/insulator onto the pigtail connectors until it stops, ensuring proper insulation.
- Secure the boot
Fasten the first cable tie at the middle of the boot/insulator and the second tie 1/4 inch from the end. Cut any excess tie flush with the head.
- Dress lead assemblies
Carefully dress the lead assemblies into the junction box, ensuring no wires are pinched or damaged.
- Verify connections
Use a multimeter to verify all connections are secure and correctly wired before powering on the system.
- Power on the system
Reconnect power to the system and monitor for any irregularities in operation.
- Calibrate the controller
Follow the manufacturer's instructions to calibrate the M2D8M-1 Controller for optimal performance.
