Overview
- Lay-in Hinged Cover Telescope Fitting allows to easily adjust wireway length from 1.00 inch (25 mm) to 7.00 inch (178 mm)
- No cutting or welding required
- 4.00 x 4.00 inch (102 x 102 mm) opening compatible with standard wireway systems
- Durable steel construction with ANSI 61 gray powder coat finish
- Meets NEMA Type 1, UL 870, and cUL C22.2 No. 26 standards
Specifications
Application | Power Distribution |
Color | Gray |
Color Code | ANSI 61 |
Finish | Galvanized;Painted |
Finish | Galvanized |
Height | 44 IN |
Height | 4 |
Height | 102 |
IP Rating | IP54 |
Material | Mild Steel;Steel |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
NEMA Rating | 12 Indoor, dust-resistant |
NEMA Rating | 12 |
Protection Rating | NEMA Type 12 |
Sealing Plate Quantity | 1 |
Sealing Plate Type | Special |
Series | Telescope Fitting Lay-In Hinged Cover |
Size | 4.00x4.00 inch (101.6x101.6 mm) |
Thickness | 51.40mm (2.024") |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | Telescope Fitting |
Type | Industrial Lay-in Wireway;Telescope Fitting |
Weight | 5.2 lb |
Width | 4 |
Width | 102 |
Width | 23 IN |
Wireway | Lay-In NEMA Type 12 Wireway |
Package Dimensions (L x W x H) | 13.6 IN x 6.4 IN x 6.1 IN |
Package Dimensions (L x W x H) | 34.544 cm x 16.256 cm x 15.494 cm |
Package Weight (Imperial) | 5.200 L |
Package Weight (Metric) | 2.359 kg |
How to Install the Lay-In Wireway
This guide provides step-by-step instructions for installing and sealing a Lay-In Wireway for electrical wiring.
Estimated time: 1h
Tools needed:
Screwdriver, Drill, Wrench
Supplies needed:
Mounting screws, Gaskets, Nuts, Sealing plates
- Assemble the wireway sections
Place a gasket between the flanges of the wireway sections and secure them using screws and nuts as shown in the assembly details.
- Seal the joints
For joints between lay-in sections, position the LSGQR fitting, leaving out the top flange screw on the hinge side. Install with a shoulder bolt and ensure gaskets are visible from above.
- Install box entries
Make a cutout in the control enclosure as specified. Position the box connector and gasket inside the enclosure, then install a sealing plate as described in the instructions.
- Adjust telescope fitting
Assemble the compression ring, gasket, and retainer on the telescope fitting. Insert the body into the straight section and adjust to the desired length.
- Anchor telescope fitting
If the telescope fitting is used vertically, drill .25 inch diameter holes through the sides and bottom of the straight section and telescope fitting. Install .25-20x.5 screws and secure with cap nuts.
- Calibrate and verify installation
After installation, verify that all joints are sealed properly and that the wireway is securely mounted. Check for grounding continuity if applicable.
