Overview
- Description: Accessories for alternative mounting options for LED enclosure lights.
- Design: Bracket for screw fixation, and magnets for magnet fixation. Adhesive magnets can be used for plastic or steel enclosures.
- Pack quantity: 2 pcs.
- The accessory ELA02MF is not intended for industrial, outdoor, or high-temperature applications.
- Designed for reliable performance in industrial settings
Specifications
Application | Power Distribution; Controls and Drives |
Color | Unpainted |
Consist Of | Magnet fixation for EL |
Construction | Mounting Accessories for EL LED Enclosure Lights, Magnet Mounting Type |
Depth | 2 mm |
Depth | 0.08 in |
Finish | Galvanized |
Height | 50 mm |
Height | 1.97 in |
Material | Mild Steel |
Mounting | Magnetic |
Mounting Type | Magnet |
Mounting Type | Magnet Mounting |
Package Quantity | 2 |
Product Family | IEC General Accessories |
Series | EL |
Size | 1.97 x 1.89 x 0.08 |
Type | IEC Enclosure Accessories |
Type | Lighting and Sockets |
Weight | 0.09 lb |
Weight | 0.04081633 kg |
Width | 1.89 in |
Width | 48 mm |
Works With | IEC |
Package Dimensions (L x W x H) | 12.3 IN x 8.86 IN x 1.2 IN |
Package Dimensions (L x W x H) | 31.242 cm x 22.5044 cm x 3.048 cm |
Package Weight (Imperial) | 0.090 L |
Package Weight (Metric) | 0.041 kg |
How to Install the ELA02MF Magnetic Mounting Kit
This guide provides step-by-step instructions for installing the ELA02MF Magnetic Mounting Kit, ensuring a secure and effective bond.
Estimated time: 24h
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws, Adhesive cleaning agent (e.g., alcohol)
- Prepare the surface
Clean the surface where the mounting kit will be applied using an adhesive cleaning agent to ensure it is dry, clean, and free of grease.
- Apply the adhesive
Press the joining surfaces of the mounting kit together with even pressure to ensure a strong bond.
- Allow curing time
Let the adhesive cure for 24 hours to achieve full adhesive strength before applying any load or stress to the mounted kit.
