ABB - Installation Products RAB 1/0-3 C - Aluminum Flood-Seal, Multi-Port Connector, RAB 1/0 Series, Conductor Range #14 - 1/0. Santoprene Coated. RUS Accepted. Total Outlets 3. Length 2-39/64 inch. Includes Caps and Screws. Contains Oxide Inhibitior.

ABB Installation Products RAB 1/0-3 C Aluminum Flood-Seal, Multi-Port Connector, RAB 1/0 Series, Conductor Range #14 - 1/0.…

UPC: 783786744947


Documents & Media
Installation InstructionsManufacturer Product Website

Contact for Pricing

Minimum Qty: 75

Multiplier: 75

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB RAB 1/0-3 C is a multi-port connector designed for reliable electrical connections in underground residential distribution (URD) applications, including direct burial, below-grade boxes, above-grade pedestals, and street light taps. Manufactured by ABB Installation Products, this connector is part of the Homac RAB 350 series, featuring a Flood-Seal design for environmental protection. Constructed from high-strength, high-conductivity 6061-T6 aluminum alloy bar, it ensures durability and conductivity. The connector is insulated with a high-performance TPE compound and includes tin-plated screws. It is 100% hi-pot tested at 4000 V for 60 seconds to ensure safety and performance. The voltage rating is 600 V, and it operates within a temperature range of -40 °F to 194 °F (-40 °C to 90 °C). This specific model, RAB 1/0-3 C, provides three (3) outlets. Its dimensions are 2-39/64 inches in length. The connector contains an oxide inhibitor to maintain electrical conductivity and prevent corrosion. It is RUS Accepted and ANSI C119.1 compliant. The SKU is RAB 1/0-3 C. Includes caps and screws.
  • High-strength, high-conductivity 6061-T6 aluminum alloy bar construction
  • Flood-Seal design for environmental protection
  • Suitable for URD direct burial, below-grade boxes, above-grade pedestals, and street light taps
  • 100% hi-pot tested at 4000 V for 60 seconds; 600 V rating

Specifications

Application
Dual-Rated Connector
Color
Black
Conductor Range
#14 to 1/0 AWG
Connection
Mechanical
Connection Type
Screw Terminal
Environmental Conditions
Waterproof
Insulation
yes
Material
6061-T6 Aluminum Connector, Santoprene Body
Material
Aluminum, Santoprene
Number of Poles
3
Poles
3
Series
RAB 1/0
Size
2-39/64 inch
Special Features
High Performance, Dual Rated Connectors
Standard
RUS Accepted
Type
Aluminum Flood-Seal Multi-Port Connector RAB 1/0 Series
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.2400 L
Package Weight (Metric)
0.1090 kg
Multi Seal, Aluminum Insulated Bus Connector, #14 - 1/0, Aluminum and Copper, Three Conductor, Orange Plug instead of Black

RAB 1/0-3 OP

Multi Seal, Aluminum Insulated Bus Connector, #14 - 1/0, Aluminum and Copper, Three Conductor, Orange Plug instead of Black
Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Ten Conductor, Dual Rated Aluminum and Copper, 10 outlets. Cap is attached by Strap.

RAB 10 C

Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Ten Conductor, Dual Rated Aluminum and Copper, 10 outlets. Cap is attached by Strap.
Aluminum Multi-Port Connectors - RAB 350 Series, conductor range 12 sol-350, length 7-1/8 inch, Oxide Inhibitor. Cap is attached by Strap.

RAB 6 C

Aluminum Multi-Port Connectors - RAB 350 Series, conductor range 12 sol-350, length 7-1/8 inch, Oxide Inhibitor. Cap is attached by Strap.
Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Seven Conductor, Dual Rated Aluminum and Copper, 10 pieces. Cap is attached by Strap.

RAB 7 C

Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Seven Conductor, Dual Rated Aluminum and Copper, 10 pieces. Cap is attached by Strap.
Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Eight Conductor, Dual Rated Aluminum and Copper, 10 pieces. Cap is attached by Strap.

RAB 8 C

Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Eight Conductor, Dual Rated Aluminum and Copper, 10 pieces. Cap is attached by Strap.
Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Nine Conductor, Dual Rated Aluminum and Copper, 10 pieces. Cap is attached by Strap.

RAB 9 C

Multi Seal, Aluminum Insulated Bus Connector, #12 - 350 kcmil, Nine Conductor, Dual Rated Aluminum and Copper, 10 pieces. Cap is attached by Strap.
Aluminum Flood-Seal Multi-Port Santoprene Insulated Bus Connector - RXL 350 Series, Cable Range #12-350 kcmil, Four Conductor, Dual Rated Aluminum and Copper, 5.8 X 4.0 X 2.63 inch, outlets 4, Orange Plug, Oxide Inhibitor.

RXL 4 C-OP

Aluminum Flood-Seal Multi-Port Santoprene Insulated Bus Connector - RXL 350 Series, Cable Range #12-350 kcmil, Four Conductor, Dual Rated Aluminum and Copper, 5.8 X 4.0 X 2.63 inch, outlets 4, Orange Plug, Oxide Inhibitor.
Aluminum Flood-Seal Multi-Port Santoprene Insulated Bus Connector - RXL 350 Series, Cable Range #2 - 1000 kcmil, Five Conductor, Dual Rated Aluminum and Copper, 7.3 X 4.0 X 2.63 inch, outlets 5, Orange Plugs, Oxide Inhibitor. Includes Cable Adapters, Plugs, Caps, Screws.

RXL 5 C-OP

Aluminum Flood-Seal Multi-Port Santoprene Insulated Bus Connector - RXL 350 Series, Cable Range #2 - 1000 kcmil, Five Conductor, Dual Rated Aluminum and Copper, 7.3 X 4.0 X 2.63 inch, outlets 5, Orange Plugs, Oxide Inhibitor. Includes Cable Adapters, Plugs, Caps, Screws.

How to Install the Multi-Seal® RAB 1/0 SERIES Connector

This guide provides step-by-step instructions for safely installing and wiring the Multi-Seal® RAB 1/0 SERIES connector, including cable preparation and final torquing.

Estimated time: 15m

Tools needed:

Torque wrench, Screwdriver, Wire strippers

Supplies needed:

Multi-Seal® RAB 1/0 SERIES connector, Electrical cable, Insulating gloves

  1. Review Safety Precautions

    Before beginning, review all safety precautions. Wear insulating gloves rated to the appropriate voltage when working on live conductors. Ensure tap conductors are not under load if installing on an energized main. Installation must be performed by trained installers in accordance with all applicable local, state, and national electrical codes, installation standards, and safety rules.

  2. Prepare the Connector Cap (Conditional)

    For #14 to #4 AWG cables, remove the connector cap. Cut the cap at the correct cut-off ring. Reinsert the cap. For #2 to 1/0 AWG cables, the cap is not required and should be omitted.

  3. Remove Screw Plug

    Remove the screw plug from the connector body.

  4. Prepare the Cable

    Measure the required strip length by placing the cable alongside the markings on the bottom of the connector. Strip the cable to the measured length using wire strippers.

  5. Insert the Cable

    Insert the prepared cable fully into the connector. For #2 to 1/0 AWG cables, insert into the tower. For #14 to #4 AWG cables, insert into the cap until fully seated.

  6. Secure the Cable

    Replace the screw plug. Using a torque wrench, torque the connector to 80 in/lbs to ensure a secure electrical and mechanical connection.

  7. Seal Unused Cable Ports

    Ensure all unused cable ports on the connector are properly sealed to prevent ingress of moisture or contaminants.
