5349

The fittings are available in trade sizes from 3/8 in to 6 in (12mm to 153mm).

The fittings have UL Type 4, 6, 12, 13 (indoor) and 3, 3R, 4, 6 (outdoor) ratings, CSA Type 3, 3R, 4, 12, 13, NEMA Type 3, 3R, 4, 6, 12, 13, and IEC IP66, IP67, IP68, IP69 ratings.

The fittings conform to UL 514B, CSA C22.2 No. 18.3, IEC/EN 61386-1, -23, RoHS, NEMA FB-1, and several JIC and Federal Specifications.

Yes, ingress ratings require the use of Series 5260 Seal Gaskets.

The part number for a 3 inch 90 degree insulated fitting is 5349.

Yes, the seal rings, insulators, and seal gaskets are halogen free.

The general operating temperature range is -20 to +105°C (-4 to +221°F) for UL/CSA, and -25 to +105°C (-13 to +221°F) for IEC/CE.

Fittings from 3/8 in to 1 1/4 in are steel, while 1 1/2 in to 6 in are malleable iron, both with Zinc Chromate finish.

They are designed for liquid-tight applications against water, oils, cutting fluids, and mild acids in indoor or outdoor locations with continuous or intermittent moisture.

Yes, they are suitable for Class I Division 2, Class II Division 1 & 2, and Class III Hazardous Locations per NEC® Section 500 and CE Code.
