ABB - Installation Products WMG-LT1 - 3/8 Inch Wire Mesh Grip Assembly, Pack of 10
More images

ABB Installation Products WMG-LT1 3/8 Inch Wire Mesh Grip Assembly, Pack of 10

UPC: 786210776231


Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 10

Multiplier: 10

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB WMG-LT1 is a pack of 10 wire mesh grip assemblies, each designed for 3/8 inch applications. Constructed from durable wire mesh, these grips provide secure strain relief and support for cables and conductors. The woven wire construction offers flexibility and conforms to the cable diameter, ensuring a firm hold without damaging the insulation. These assemblies are essential for maintaining the integrity of electrical connections by preventing undue stress on terminals and connectors. The 3/8 inch size is suitable for a range of medium-duty cable installations where reliable support is critical. ABB, a recognized name in installation products, ensures consistent quality in manufacturing these grips. The WMG-LT1 is a practical choice for electricians, maintenance personnel, and contractors working on industrial, commercial, or utility projects. Each pack contains 10 units, offering an economical solution for multiple installation points. The material's inherent strength and resilience make it effective in preventing cable sag and potential disconnection due to vibration or movement. This product is a direct component for ensuring the longevity and safety of electrical systems by managing cable tension effectively. Its straightforward design facilitates quick and easy installation, contributing to efficient project timelines.
  • Pack of 10 wire mesh grip assemblies
  • Designed for 3/8 Inch cable applications
  • Constructed from durable wire mesh
  • Provides secure strain relief and support
  • Manufactured by ABB - Installation Products

Specifications

Application
Prevents Severe Conduit Bends and Pullout
Material
Stainless Steel
Material
Wire Mesh
Series
WMG-LT
Size
3/8 Inch
Size
1/2 Inch
Standard
UL E23018, CSA
Type
Wiremesh Grips
Package Dimensions (L x W x H)
6 IN x 4.5 IN x 3 IN
Package Dimensions (L x W x H)
15.24 cm x 11.43 cm x 7.62 cm
Package Weight (Imperial)
0.0800 L
Package Weight (Metric)
0.0360 kg
Liqua-Seal Connector, straight, insulated, 1/2" NPT, SS, with o-ring

LMSS-12

Liqua-Seal Connector, straight, insulated, 1/2" NPT, SS, with o-ring
Liquid Tight Fitting for Conduit, ATEX Flameproof G1 Gland, Straight with External Male Thread, Conduit Size 20mm, M20 Thread, CSA, Group I & II, Zones 1, 2, 21 and 22, Class I Div2 ABCD, Class II Div1 EFG, Stainless Steel with Epoxy Resin Barrier

HAMS0404G1

Liquid Tight Fitting for Conduit, ATEX Flameproof G1 Gland, Straight with External Male Thread, Conduit Size 20mm, M20 Thread, CSA, Group I & II, Zones 1, 2, 21 and 22, Class I Div2 ABCD, Class II Div1 EFG, Stainless Steel with Epoxy Resin Barrier
1 Inch Wire Mesh Grip Assembly, Pack of 10

WMG-LT4

1 Inch Wire Mesh Grip Assembly, Pack of 10
1-1/2 Inch Wire Mesh Grip Assembly, Pack of 2

WMG-LT6

1-1/2 Inch Wire Mesh Grip Assembly, Pack of 2
2 Inch Liquidtight Fitting, Metal Conduit Connector, Straight, Insulated, Safe-edge Ground Cone, In K.O. Applications Use Sealing Ring #5267, Electro Zinc Plated to Chrome Coated, UL Listed Type 6, 5 Pieces

5337-T6

2 Inch Liquidtight Fitting, Metal Conduit Connector, Straight, Insulated, Safe-edge Ground Cone, In K.O. Applications Use Sealing Ring #5267, Electro Zinc Plated to Chrome Coated, UL Listed Type 6, 5 Pieces
1/2 Inch Stainless Steel Type A Liquidtight Straight Connector With Santoprene Sealing Gasket and Stainless Steel Retaining Ring

6302SST

1/2 Inch Stainless Steel Type A Liquidtight Straight Connector With Santoprene Sealing Gasket and Stainless Steel Retaining Ring
3/4 Inch Stainless Steel Type A Liquidtight Straight Connector With Santoprene Sealing Gasket and Stainless Steel Retaining Ring

6303SST

3/4 Inch Stainless Steel Type A Liquidtight Straight Connector With Santoprene Sealing Gasket and Stainless Steel Retaining Ring
1-1/4 Inch Stainless Steel Type A Liquidtight Straight Connector With Santoprene Sealing Gasket and Stainless Steel Retaining Ring

6305SST

1-1/4 Inch Stainless Steel Type A Liquidtight Straight Connector With Santoprene Sealing Gasket and Stainless Steel Retaining Ring

How to Install T&B Liquidtight Connectors with Grips

This guide provides step-by-step instructions for the proper installation of T&B Liquidtight flexible metallic conduit connectors, ensuring high performance and reliability for various applications.

Estimated time: 15m

Tools needed:

Hacksaw (32 Tooth/In no set or 24-32 Tooth/In wavy set power band saw), Flat nose pliers (optional), Torque wrench

Supplies needed:

T&B Liquidtight Connector (with gland nut, grip, sealing ring, ground cone, body), Flexible metallic conduit, T&B 140 Series locknuts (for knockout applications, if needed), T&B 5262 Series sealing o-rings (for knockout applications, if needed)

  1. Cut the Flexible Conduit

    Cut the flexible metallic conduit with a clean, square end. Use a sharp hacksaw (32 Tooth/In no set) or, for high production, a power band saw (24-32 Tooth/In wavy set, not exceeding 400 surface feet per minute). Ensure you are using metal liquid tight conduit. CAUTION: DO NOT USE AN ABRASIVE WHEEL for cutting.

  2. Slide Grip and Sealing Ring onto Conduit

    Slide the grip assembly, including the gland-nut, onto the conduit. Next, slide the one-piece sealing ring onto the conduit. If installing at maximum cord diameter, pre-form the endless weave mesh of the grip by carefully using flat nose pliers to round each loop, which will facilitate installation.

  3. Screw in the Ground Cone

    Screw the Safe-Edge steel grounding cone tightly into the clean, square end of the flexible conduit.

  4. Seat the Sealing Ring

    Push the sealing ring along the conduit towards the ground cone until it is fully seated into the ground cone flange.

  5. Insert Ground Cone into Connector Body

    Insert the assembled ground cone and the end of the conduit into the main body of the T&B Liquidtight connector.

  6. Tighten the Gland Nut

    Push the end of the grip along the conduit towards the connector body and screw the gland nut onto the body. Tighten the gland nut to the specified torque value for the fitting's trade size (refer to the torque table provided in the original documentation). After tightening, verify that the grip is laying flat and fully extended along the conduit.
