ABB Installation Products 35MTB5-D Kellums bracket for tri-mounting fits overall cable O.D. from 1.5 inch to 2 inch
UPC: 783786444755
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Tri-mounting design for enhanced cable stability
- Accommodates cable O.D. from 1.5 inches to 2 inches
- Manufacturer: ABB - Installation Products
- SKU: 35MTB5-D
- Facilitates secure cable management and strain relief
Specifications
Application | Terminator Mounting Bracket |
Material | Galvanized Steel |
Mounting | Mechanical |
Mounting Type | Tri-mounting |
Series | 35MTB5 |
Size | Fits overall cable O.D. from 1.5 inch to 2 inch |
Size | 1.5 inch to 2 inch |
Temperature Rating, Maximum | 149 F |
Temperature Rating, Maximum | 65 C |
Temperature Rating, Minimum | -40 F |
Temperature Rating, Minimum | -40 C |
Type | Mounting Bracket |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 1.0000 L |
Package Weight (Metric) | 0.4540 kg |
K650CAM-OK
Operating Kit 25kv Cam-Op, includes accessories that enable visible break, testing isolation and grounding functions to be preformed. Kit includes - (3) Cam-Op Loadbreak Tap Plugs, (3) Grounding Elbows, (1) Assembly Tool, (1) Test Rod, (1) Carry Case, (1) Lubricant and (1) Set of Instructions.How to Install the 35MTB1-T Bracket Assembly
This guide provides step-by-step instructions for mounting the 35MTB1-T bracket assembly, preparing the cable, and installing a premolded rubber terminator, ensuring proper support and grounding.
Estimated time: 30m
Tools needed:
Wrench or Socket Set, Wire Strippers, Cable Cutters
Supplies needed:
Connector Grip, Mounting Bracket Bolts, Weather-proof Plastic Tape, Premolded Rubber Terminator
- Ensure Safety and Prepare for Installation
DANGER: All apparatus must be de-energized during installation or removal of parts. This product should be installed only by competent personnel trained in good safety practices involving high voltage electrical equipment. Inspect all parts for damage, rating, and compatibility with mating parts. Check the contents of the package to ensure they are complete and undamaged, and verify proper fit with the cable and/or mating products. Have all required tools at hand and maintain cleanliness throughout the procedure.
- Mount Connector Grip and Prepare Cable
Attach the connector grip to a suitable bracket using the bolts supplied with the bracket. Tie back the concentric neutral wires for the length specified in the terminator instructions plus dimension 'X' from the provided table. Prepare the cable as required for installing the terminator. Feed the prepared cable through the connector grip until the semi-conducting shield is at least 1-3/4 inches (45 mm) above the connector grip. Apply weather-proof plastic tape approximately two inches (50 mm) from the bottom end of the wire grip, tightly wrapping with a one-half tape width overlap 'down' the grip approximately one inch (25 mm) onto the cable.
- Install Terminator and Ground System
Clean the outer jacket and the exposed cable insulation above the connector grip. Install the terminator according to the specific instructions packed with the terminator. Ensure that the concentric neutral from the cable(s), the electrostatic drain wire(s) from the terminator(s), and the mounting bracket are all properly grounded to complete the installation.
