2702A1

The Elastimold 2702A1 is a 25kV class, 200 Amp load break feed-thru bushing insert.

The 2702A1 features peroxide-cured insulation and jacket.

The 15-minute DC withstand voltage is 78kV.

The one-minute AC withstand voltage is 40kV.

It is easily installed in an ELASTIMOLD universal bushing well and mated with an appropriate ELASTIMOLD product.

It includes the feed-thru bushing insert, protective shipping caps, a bail assembly, lubricant, and installation instructions.

It connects shielded cable to transformers, generators, switchgear, regulators, and reclosers.

The 2702A1 conforms to ANSI/IEEE Standard 386, including Fig. 3 and Fig. 7 for bushing wells.

The momentary and fault close rating is 10kA Symmetrical for 10 cycles.

The continuous and loadbreak current rating for the 2702A1 is 200 Amp.
