Contact for Pricing
Overview
- Five-micron airline filter, 115 V solenoid
- Thermostat
- Ducting kit
- Cooling capacities to 2500 BTU/Hr. (733 W)
- Durable brushed aluminum construction
Specifications
Application | Controls and Drives;Power Distribution |
Application | Power Distribution; Controls and Drives |
Btu Rating | 1,500 |
Color | Unpainted |
Color | Brushed aluminum |
Depth | 1.75 in |
Depth | 44 mm |
Finish | Brushed |
Frequency | 50/60 Hz |
Frequency Rating | 50/60 Hz |
Frequency Rating, Maximum | 60 Hz |
Frequency Rating, Minimum | 50 Hz |
Height | 10.75 in |
Height | 273 mm |
Material | Aluminum |
Nominal Capacity Btu/h | 1,500 Btu/h |
Nominal Capacity Watts | 440 W |
Nominal Voltage | 115 V |
Product Family | Vortex |
Type | Vortex Coolers |
Voltage AC | 100-120 V |
Voltage Rating | 115 V |
Voltage Rating | 115V |
Weight | 2.72 kg |
Weight | 5 lb |
Width | 44 mm |
Width | 1.75 IN |
Package Dimensions (L x W x H) | 12.7 IN x 9.5 IN x 4.5 IN |
Package Dimensions (L x W x H) | 32.258 cm x 24.13 cm x 11.43 cm |
Package Weight (Imperial) | 5.000 L |
Package Weight (Metric) | 2.268 kg |
How to Install the VC1516012 VCool System
This guide provides step-by-step instructions for installing and configuring the VC1516012 VCool System for effective cooling of industrial cabinets.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Locknut, Ducting kit
- Prepare the enclosure
Cut a 1-1/8” hole in the enclosure using a suitable tool for the knockout size.
- Install the VCool unit
Insert the VC1516012 VCool into the cut-out hole and secure it with the provided locknut.
- Attach the ducting kit
Perforate the ducting kit with several 1/8” holes and secure it to the interior of the enclosure, then connect it to the cold outlet of the VCool.
- Connect the components
Wire the compressed air filter, solenoid valve, and thermostat to the VCool, ensuring the thermostat is directly wired to the solenoid valve.
- Connect the air supply
Connect the compressed air supply to the filter, ensuring it is installed close to the VCool and in a location where the temperature does not exceed 125°F (52°C).
- Verify installation
Check all connections and ensure the VCool is securely mounted and properly wired before applying power.
