Contact for Pricing
Overview
- Set screws and cable ties are included
- Surface mounting fasteners are not provided
- Pre-drilled M10 holes are provided at the four corners for attaching to casters or leveling feet
- Direct attachment compatible with Syspend 281-Max tubes
- Compatible with accessory casters and levelers for installation flexibility
Specifications
Application | Controls and Drives |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Depth | 15.75 |
Depth | 400 |
Finish | Powder Coated |
Height | 0.39 |
Height | 10 |
Material | Steel |
Material | Aluminum |
Modification Services | Yes |
Mounting Type | Floor-mounted |
Product Family | Syspend 281-Max |
Series | Syspend 281-Max |
Size | 15.83x15.83x4.41 in |
Type | Syspend 281-Max |
Weight | 30.9 lb |
Width | 15.75 |
Width | 400 |
Package Dimensions (L x W x H) | 16.4 IN x 16.2 IN x 5.4 IN |
Package Dimensions (L x W x H) | 41.656 cm x 41.148 cm x 13.716 cm |
Package Weight (Imperial) | 30.900 L |
Package Weight (Metric) | 14.016 kg |
CCCH300
OI Handle Kit, Straight (Qty 2), Bulletin CC1 (COMPACT® "CC1" Operator Interface Enclosures - COMPACT Operator Interface "CC1" Enclosures), Size/Dims: 300mm, Material: Aluminum, Finish:
How to Install the S2MPBS Suspension System
This guide provides step-by-step instructions for mounting and configuring the S2MPBS suspension system for optimal performance.
Estimated time: 1h
Tools needed:
Screwdriver, Torque wrench, Allen key
Supplies needed:
Mounting screws, Gaskets, Retaining washers
- Mount the tube
Position the tube vertically or horizontally as required. Press the gasket flat and tighten screws until they are flush on the inside. Ensure to maintain pressure while tightening screws to 20 Nm.
- Align the tube
Check the alignment of the tube. Adjust by loosening screws and tightening them in the correct sequence to ensure no play exists. Verify that the gap is a maximum of 4.4 mm.
- Secure the enclosure
Attach the enclosure to the tube using the appropriate screws and retaining washers. Tighten screws to a torque of 6 Nm to ensure a secure fit.
- Calibrate the system
Unscrew the cover and adjust the swing torque by tightening the threaded sleeve. Ensure the desired torque is set correctly before reattaching the cover.
