Overview
- Assembled Syspend 281 HMI Arm System has a max weight load of 281 lb. (127.7 kg)
- RAL 9005 black polyester powder-coated finish
- Tapped mounting holes for HMI adapters (cutout, swivel, tilt, angle)
- Compatible with nVent Syspend 281-Max Suspension System
- Pre-drilled for floor bolting or optional caster attachment
Specifications
Application | Controls and Drives |
Color | Black |
Color | Jet Black |
Color Code | RAL 9005 |
Depth | 600 mm |
Depth | 23.62 |
Depth | 600 |
Finish | Powder Coated |
Height | 2.36 |
Height | 60 |
Height | 60 mm |
Material | Aluminum |
Material | Cast Aluminum |
Modification Services | Yes |
Mounting Type | Surface Mounting |
Product Family | Syspend 281-Max |
Series | Syspend 281-Max |
Size | 24.21x22.24x6.30 in |
Size | 24.21x22.24x6.30 |
Type | Syspend 281-Max |
Weight | 30.8 lb |
Weight | 25.7 lb. lb |
Width | 21.65 |
Width | 550 |
Width | 549 mm |
Package Dimensions (L x W x H) | 24.3 IN x 22.8 IN x 7.3 IN |
Package Dimensions (L x W x H) | 61.722 cm x 57.912 cm x 18.542 cm |
Package Weight (Imperial) | 30.800 L |
Package Weight (Metric) | 13.971 kg |
