nVent
MM2006
UPC: 783510506889
Contact for Pricing
Overview
- Description: Connector plate between two enclosures, or to be used in combination with a raised side door (DNSR). Hole pattern for 24 pin connectors. With MMG cover plates, it can be adapted to 16 pin connectors. Must be mounted with the CCJ06 bracket set
- Material: 2 mm zinc plated steel.
- Pack quantity: 1 piece.
- Mounting requirements: Add CCJ06. Add raised side door DNSR for covering and protection of the connection. Add cover plates MMG for unused cut-outs or to adapt to different connector sizes.
- The marshalling plate can be mounted easily either between two bayed enclosures or between an enclosure and a raised side door
- The plate allows for 24-pin connectors to be installed
- Connectors can be installed easily which will reduce the required labour time
- If a side door has been used, operations can be carried out while the main enclosure maintains its protection degree
- Separation brackets, CCJ, are required in order to mount the marshalling plate
- Cover plates, MMG, can be used if the pin cut-outs need to be adapted or covered up
Specifications
Depth | 23.62 in |
Depth | 600 mm |
Enclosure Material | Zinc |
Finish | Plated |
Height | 2,000 mm |
Height | 78.74 in |
Material | Zinc |
Material | Zinc-Plated Steel |
Mounting Type | Enclosure Mounting |
Mounting Type | Pre-drilled mounting holes |
Series | Hoffman enclosure accessories |
Size | 2000x600 mm |
Size | 2000x600 |
Thickness | 0.08 in |
Thickness | 51.40mm (2.024") |
Type | Cable Management |
Width | 0.49 in |
Width | 12.5 mm |
Works With | IEC |
