Overview
- Click-Fit design quickly installs into enclosure wall; no tools or screws required
- Opens with the flick of a finger for easy filter replacement
- Enclosure side wall mounting
- Reverse airflow option on HF13 models available to push/pull air through higher static pressure
- Standard rope gasket provides proper seal to the enclosure
- Similar cut-out sizes as other filter fan manufacturers
- Terminal block connections
- Optional thermostat available to save energy and extend service life
- Hinged grille remains attached after opening
- Size rage from 4 inch (102 mm) to 13 inch (325 mm)
Specifications
Airflow | 175 m³/h |
Airflow | 103 ft³/min |
Ambient Temperature | 14 to 131 deg F |
Ambient Temperature, Maximum | 131 F |
Ambient Temperature, Maximum | 55 C |
Ambient Temperature, Minimum | 14 F |
Ambient Temperature, Minimum | -10 C |
Amperage Rating | 0.38/0.36 A |
Application | Controls and Drives;Power Distribution |
Color | Black |
Color | Graphite Black |
Color Code | RAL 9011 |
Depth | 4.68 in |
Depth | 119 mm |
Finish | Smooth Matte |
Finish | Black;Smooth Matte |
Flow Rate | 103 CFM |
Height | 10.13 in |
Height | 257 mm |
Housing Material | Non-metallic |
IP Rating | IP55 |
Material | Plastic/Composite |
Material | Plastic |
Max Current | 0.38 A |
Mounting Type | Side-Mount |
Nema Rating | Type 12 |
Nominal Voltage | 115 V |
Operating Temperature | -40 to 60 |
Operating Temperature | 14-131 °F |
Series | HF10 |
Series | HF |
Size | 10.13" H x 10.14" W x 4.68" D |
Size | 10 in |
Size | 10.13 x 10.14 x 4.68 in |
Type | Fans and Filter Fans |
Voltage AC | 100-100 V |
Voltage Rating | 115 VAC |
Voltage Rating | 115 V |
Weight | 1 lb |
Weight | 1.4 kg |
Width | 258 mm |
Width | 10.14 in |
Package Dimensions (L x W x H) | 12 IN x 10 IN x 12 IN |
Package Dimensions (L x W x H) | 30.48 cm x 25.4 cm x 30.48 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
Frequently Asked Questions
What is the airflow rate of the nVent HF10 filter fan?
The nVent HF10 filter fan provides 103 CFM (175 m³/hr) of free airflow.
What is the IP rating of this nVent filter fan?
This HF10 filter fan is IP55 rated, suitable for Type 12 enclosures.
What is the operating voltage for the HF1016513 filter fan?
The nVent HF1016513 filter fan operates on 115V AC.
What are the dimensions of the nVent HF10 filter fan?
The unit dimensions are 10.13" H x 10.14" W x 4.68" D, with an 8.78" x 8.78" cutout.
What is the service life of the nVent HF10 filter fan?
The filter fan has a service life of 97,000 hours at 40°C.
What is the operating temperature range for this filter fan?
The HF10 filter fan operates reliably between -10°C and 55°C.
Does the HF10 filter fan require tools for installation?
No, the HF10 features a tool-free click-fit installation system.
How to Install the Side-Mount Filter Fans and Grilles
This guide provides step-by-step instructions for installing side-mount filter fans and grilles in an enclosure, ensuring proper fit and functionality.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Drill, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Cutout template
- Prepare the enclosure
Apply the cutout template to the desired location on the side of the enclosure. Ensure it is aligned properly before proceeding.
- Cut the opening
Using the appropriate cutting tool, cut out the hole in the enclosure according to the size specified for your model. Deburr the cutting edge to avoid sharp edges.
- Insert the fan or grille
Insert the fan or grille into the cutout opening and push until all four corners snap and lock into place.
- Secure the installation
If the enclosure material thickness is between 0.10 (2.5 mm) and 0.14 (3.5 mm), install mounting fasteners. For thickness greater than 0.14 (3.5 mm), ensure fasteners are used to maintain the IP/Type 12 rating.
- Wire the filter fan
Follow the wire diagrams provided in the manual to connect the filter fan to the power supply, ensuring all connections are secure.
- Verify clearance
Ensure that the installed filter fan has a minimum clearance of 7.00 (178 mm) from any obstructions to allow for proper airflow.
