Contact for Pricing
Overview
- Spring-loaded, self-retained hinge pins allow door removal
- Reversible door fits flush to body with no exposed corners
- Knockouts for 4-inch fan on top and bottom of enclosure
- Wiring knockouts (7/8 inch, 1-3/8 inch, and 3 inch) on top and bottom of enclosure; two 3-inch cable entry knockouts on back
- 120-degree door opening for maximum equipment access
- Multiple cable tie-down points on back of enclosure
- Quarter-turn latch with key lock
- Keyhole mounting slots spaced 16.00 inch (406 mm) on center for easy enclosure mounting
- Bosses provided for mounting accessories such as cable spools
- Patch panel 4U mounting angles rotate down for access
Specifications
Application | Networking, Storage and Data Center |
Body Thickness | 16 ga |
Body Thickness | 1.52 mm |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 313 mm |
Depth | 12.34 in |
Depth | 12.34 |
Depth | 313 |
Door Thickness | 1.9 mm |
Door Thickness | 14 ga |
Finish | Powder Coated |
Finish | Powder Coating;Steel/LtGray |
Height | 48 |
Height | 1,219 |
Height | 48 in |
Height | 1,219 mm |
IP Rating | IP30 |
Ip Rating | IP40 |
Material | Mild Steel |
Material | Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | EIA Universal Tapped 10-32 |
NEMA Rating | Type 1 |
NEMA Rating | 1 |
NEMA Rating | 1 Indoor, electrical protection |
Product Family | D-Box |
Protection Rating | NEMA Type 1 |
Rack Units | 6 |
Series | D-Box |
Series | nVent D-BOX Type 1 |
Size | 48.00x24.00x12.00 |
Size | 48.00" x 24.00" x 12.00" |
Type | Data Networking Wall Mounted Cabinets |
Type Number | Type 1 |
Weight | 89 lb |
Width | 24 in |
Width | 610 mm |
Width | 24 |
Width | 610 |
Package Dimensions (L x W x H) | 52.5 IN x 29.25 IN x 17 IN |
Package Dimensions (L x W x H) | 133.35 cm x 74.295 cm x 43.18 cm |
Package Weight (Imperial) | 89.000 L |
Package Weight (Metric) | 40.370 kg |
