Contact for Pricing
Overview
- Spring-loaded, self-retained hinge pins allow door removal
- 120-degree door opening for maximum eqiupment access
- Quarter-turn latches with key lock
- One set of fixed rack angles is included on 24- and 36-inch (610- and 914-mm) tall models and two on 48-inch (1219-mm) tall models
- Rack angles on 36-inch (914-mm) models can be positioned either at the top or the bottom of the cabinet
- 36- and 48-inch (914- and 1219-mm) tall models have space for patch panel or shelf brackets
- Knockouts for 4-inch (102-mm) fan on top and bottom of cabinet
- Wiring knockouts (7/8 inch, 1-3/8 inch, and 3 inch) on top and bottom of cabinet & two 3-inch cable entry knockouts on back
- Multiple cable tie-down points on back of cabinet
- Keyhole mounting slots spaced 16.00 inch (406 mm) on center for easy cabinet mounting
Specifications
Application | Networking, Storage and Data Center |
Color | Light Gray |
Color | Lt Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Depth | 12.34 |
Depth | 313 |
Depth | 12.34 in |
Depth | 313 mm |
Finish | Powder Coating;Steel/LtGray |
Finish | Powder Coated |
Height | 48 in |
Height | 1,219 mm |
Height | 48 |
Height | 1,219 |
IP Rating | IP30 |
Material | Mild Steel;Steel |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Wall-mount |
NEMA Rating | 1 |
NEMA Rating | 1 Indoor, electrical protection |
Product Family | L-Box |
Protection Rating | NEMA Type 1 |
Rack Units | 12 |
Series | L-Box Type 1 |
Size | 48.00x24.00x12.00 |
Thickness | 1.9 mm |
Thickness | 14 |
Thickness | 1.9 |
Type | Data Networking Wall Mounted Cabinets |
Type Number | Type 1 |
Weight | 95 lb |
Width | 610 mm |
Width | 24 in |
Width | 24 |
Width | 610 |
Package Dimensions (L x W x H) | 53 IN x 42 IN x 41 IN |
Package Dimensions (L x W x H) | 134.62 cm x 106.68 cm x 104.14 cm |
Package Weight (Imperial) | 70.000 L |
Package Weight (Metric) | 31.752 kg |
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
How to Install the DBL482412G Wall-Mount Enclosure
This guide provides step-by-step instructions for installing and configuring the DBL482412G wall-mount enclosure.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Remove the support bracket
If additional rack spacing is required, remove the support bracket from the enclosure.
- Mount the enclosure
Secure the enclosure to the wall using appropriate mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the terminal connectors inside the enclosure. Verify connections with a multimeter.
