Contact for Pricing
Overview
- 30A single-phase power distribution at 208V
- (30) C13 and (6) C19 outlets for versatile equipment compatibility
- NEMA L6-30P input plug with 10-foot (3m) power cord
- Monitored and switched outlets for remote power control and status tracking
- Durable black enclosure for rack or cabinet mounting
Specifications
Package Dimensions (L x W x H) | 78 IN x 8.2 IN x 4.6 IN |
Package Weight (Imperial) | 20.3 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the maximum operating temperature for the PDU?
The PDU can operate at a maximum temperature of 140°F (60°C) at full load.
What is the warranty period for the PDU?
The PDU comes with a 3-year standard warranty and a 5-year extended warranty option.
Is the PDU compatible with Cisco systems?
Yes, the PDU is compatible with Cisco Nexus Dashboard software for enhanced energy management.
What safety features does the PDU include?
The PDU is equipped with built-in magnetic hydraulic circuit breakers for protection against overloads.
Are there any security features in the PDU?
Yes, the PDU includes enhanced security features such as certificate-based encryption and access control.
How do I install the PDU?
The PDU features tool-less mounting buttons for quick and secure installation into racks.
What types of outlets does the PDU have?
The PDU features a mix of C13 and C19 outlets, providing flexibility for various equipment needs.
Can the PDU be monitored remotely?
Yes, the PDU offers remote monitoring capabilities through network integration for power data.
What is the power capacity of the PDU?
The PDU supports power capacities ranging from 5kW to 27.6kW, depending on the model.
What are the environmental monitoring capabilities?
The PDU includes environmental monitoring features to protect IT assets from temperature and humidity threats.
How to Install the Panduit G6 PDU
This guide provides step-by-step instructions for installing and configuring the Panduit G6 Power Distribution Unit (PDU) in a data center rack.
Estimated time: 1h
Tools needed:
Phillips screwdriver, Torx screwdriver, Multimeter
Supplies needed:
Mounting screws, Ground bonding cable, Terminal connectors
- Mount the PDU
Align and install the mounting buttons with the screw holes on the sides of the PDU. Insert the mounting buttons into the keyhole slots on the PDU mounting bracket in the rack to secure the PDU.
- Connect the Ground Bonding Cable
Attach the ground bonding cable to the external ground bonding point located on the chassis of the PDU. Ensure that the other end is securely connected to a grounding strip or bus bar.
- Connect the PDU to Power Source
Turn off the feed circuit breaker. Connect the PDU to an appropriately rated branch circuit, ensuring all circuit breakers on the PDU are set to On. Finally, turn the feed circuit breaker back on.
- Configure the PDU Input Type
Access the PDU's web interface and navigate to the System Management page. Select 'Set Input Cord' and choose the correct cord type from the dropdown menu. Save the settings to complete the configuration.
