NSI Industries M22-250-3V-BULK - 22-18 AWG Male Disconnect, Bulk

NSI Industries M22-250-3V-BULK 22-18 AWG Male Disconnect, Bulk

UPC: 662381682451


Documents & Media
Technical Bulletin

Contact for Pricing

Minimum Qty: 1000

Multiplier: 1000

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

NSI Industries M22-250-3V-BULK is a bulk pack of 1000 vinyl-insulated male disconnect terminals. Designed for 22-18 AWG wire, these terminals feature a 0.250" stud size and are rated for 300V and 75°C. The butted seam construction enhances durability. Packaged in bulk for cost-effective large-scale projects.
  • Wire range: 22-18 AWG
  • Stud size: 0.250"
  • Electrical rating: 300V, 75°C
  • Bulk pack quantity: 1000 pieces
  • Bulk Pack: 1000 pieces

Specifications

Color
Red
Connection Type
Male Disconnect
Environmental Conditions
75 C
Mounting Type
Bulk Pack
Number Of Terminals
1
Series
M22
Size
22-18 AWG
Terminal Size
.250 x .032 IN
Voltage Rating
300 V
Warranty
1 Year
Package Dimensions (L x W x H)
0.834 IN x 0.249 IN x 0.036 IN
Package Dimensions (L x W x H)
21.1836 mm x 6.3246 mm x 0.9144 mm
Package Weight (Imperial)
2.220 L
Package Weight (Metric)
1.007 kg
