NSI Industries M22-250-3V - 22-18 AWG Male Disconnect, 100 Per Pack
NSI Industries

M22-250-3V

UPC: 662381069160

Documents & Media
Technical Bulletin

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Overview

The NSI Industries M22-250-3V is a vinyl-insulated male disconnect terminal designed for reliable electrical connections. This component is part of NSI's MINITERMS line and is specifically engineered for 22-18 AWG wire sizes. It features a construction of electro-tin plated copper with a butted seam, ensuring a secure and efficient electrical pathway. The M22-250-3V is rated for a maximum voltage of 300V and a temperature of 75°C, meeting cULus standards for safety and durability in industrial applications. Supplied in a convenient 100-piece pack, these male disconnects are ideal for use in industrial, automotive, and appliance wiring where insulated and dependable connections are essential. They are compatible with standard disconnect terminals and offer a push-on mounting type for straightforward installation. SKU: M22-250-3V. Manufacturer: NSI Industries. Country of Origin: US.
  • Vinyl insulated male disconnect terminal
  • Designed for 22-18 AWG wire sizes
  • Electro-tin plated copper construction with a butted seam
  • Rated for 300V and 75°C
  • 100-piece pack for industrial, automotive, and appliance wiring

Specifications

Color
Red
Connection Type
Male Disconnect
Environmental Conditions
75 C
Number Of Terminals
1
Series
M22-250-3V
Size
22-18 AWG
Terminal Size
.250 x .032 IN
Voltage Rating
300 V
Warranty
1 Year
Package Dimensions (L x W x H)
0.834 IN x 0.249 IN x 0.036 IN
Package Dimensions (L x W x H)
21.1836 mm x 6.3246 mm x 0.9144 mm
Package Weight (Imperial)
0.222 L
Package Weight (Metric)
0.101 kg
