NSI Industries L1N-141 - 2 Hole Long Barrel Copper Compression Lug 1 AWG - 1/4" Bolt Long Barrel Copper Compression Lugs are produced from high conductivity copper tubing. Allows easy inspection of the termination to assure complete cable insertion. Tin-plated to provide corrosion and low contact resistance. Marked with die index and color coded. Listed for 35KV maximum when properly installed. Rated 600V. cULus 486A/B Listed. UL467 Listed on sizes 6 AWG - 3/0 AWG. Temperature rating 90 degrees C.
NSI Industries

L1N-141

UPC: 662381339089

Documents & Media
Technical BulletinInstallation Instructions

Contact for Pricing

Overview

The NSI Industries L1N-141 is a two-hole, long barrel copper compression lug designed for reliable electrical terminations. Manufactured from high-conductivity copper tubing, this lug ensures excellent electrical performance and durability. Its tin plating provides superior corrosion resistance and maintains low contact resistance over time, crucial for maintaining signal integrity and preventing power loss. The long barrel design facilitates easy inspection of the termination, allowing visual confirmation of complete cable insertion, which is vital for safe and effective connections. This lug is marked with a die index and color-coded for quick identification and proper tooling selection, streamlining installation processes. Rated for 600V and 90°C, the L1N-141 is cULus 486A/B Listed, ensuring compliance with stringent safety standards. It is also UL467 Listed for grounding and bonding applications on sizes 6 AWG through 3/0 AWG, offering versatility. For applications exceeding 2000V, proper installation according to the cable manufacturer's voltage stress relief instructions is recommended, and it is listed for 35KV maximum when properly installed. The L1N-141 is designed for use with 1 AWG wire and features a 1/4" bolt size for secure mounting. Its robust construction and adherence to industry standards make it an ideal choice for demanding electrical infrastructure and industrial applications where reliable and long-lasting connections are paramount. Country of Origin: US.
  • Constructed from high-conductivity copper tubing for optimal electrical performance.
  • Tin-plated for superior corrosion resistance and low contact resistance.
  • Long barrel design allows for easy visual inspection of cable insertion.
  • Marked with die index and color-coded for efficient installation.
  • Rated 600V, 90°C, cULus 486A/B Listed, and UL467 Listed for grounding/bonding (sizes 6 AWG - 3/0 AWG).

Specifications

Application
Terminate, Splice, Tap Power Connectors
Cable Size
# 1 AWG (STR)
Color
Green
Connection Type
Compression Lug
Environmental Conditions
90 C
Finish
Tin Plated
Material
Copper
Mounting
1/4 Mounting Holes
Number Of Holes
2
Size
L=2.56 - W=.670 - OD=.470 - ID=.360
Size
1 AWG
Special Features
# 1 AWG (STR) - 1/4 Mountign Holes - 5/8 Hole Spacing
Standard
UL486A/B, UL467 (8 AWG -3/0 AWG)
Stud Size
1/4 IN
Type
Long Barrel - Two Hole
Voltage Rating
600 V
Warranty
1 Year
Package Dimensions (L x W x H)
2.56 IN x 0.67 IN x 0.47 IN
Package Dimensions (L x W x H)
6.5024 cm x 17.018 mm x 11.938 mm
Package Weight (Imperial)
5.000 L
Package Weight (Metric)
2.268 kg
