Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Essential grounding solution for junction and pull boxes
- Compatible with Hammond CSG and CSKOG series junction boxes
- Includes mounting hardware for easy installation
Specifications
Brand Name | Hammond Mfg. |
Connection Type | Cu-Al Monopiece Connectors |
Mounting Type | Mounting hardware included |
Series | CSG, CSKOG |
Sub Brand | CGK Series |
Package Dimensions (L x W x H) | 1 IN x 1 IN x 1 IN |
Package Dimensions (L x W x H) | 2.54 cm x 2.54 cm x 2.54 cm |
Package Weight (Imperial) | 1.000 L |
Package Weight (Metric) | 0.454 kg |
RDC1/0
Ratchet Drive Crimping Tool APPLICATIONS: Ratchet Drive Crimping Tool is for non-insulated terminals from 6 to 1/0 AWG and insulated terminals from 22 to 8 AWG. Rugged, compact, and lightweight. Requires minimum effort due to ratchet action, ensuring an excellent crimp every time. FEATURES: TYPE: Insulated and Uninsulated ACTION: Ratchet INSULATED USE: Terminals 22 to 8 AWG NON-INSULATED USE: Terminals 6 to 1/0 AWG MANUFACTURER: NSi Industries PART NUMBER: RDC 1/0 UPC: 662381055309
F4-PS-W-NP
Non-Insulated Parallel Splice Connector For Wire Range #4 AWG, Circular Mil Range 33,100-52,600, Length 0.531 Diameter 0.41, Nickel Plated
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
Frequently Asked Questions
What types of conductors can be used with CGK grounding kits?
CGK grounding kits are designed for use with both aluminum and copper conductors.
What is the temperature rating for the lugs in CGK grounding kits?
The lugs are constructed from aluminum alloy 6061-T6 and are rated at 90°C.
Are mounting hardware included with the CGK grounding kits?
Yes, the kits are supplied with all necessary mounting hardware.
Is the CGK series CSA Certified?
Yes, the CGK series is CSA Certified.
What wire sizes are supported by the CGK125 splitter box?
The CGK125 supports 4 circuits with wire sizes ranging from 2 to 14 AWG for copper or aluminum.
What is the maximum amperage for the CGK400 splitter box/trough?
The CGK400 splitter box/trough is rated for 400 A.
What wire sizes does the CGK600 splitter box/trough support?
The CGK600 supports 7 circuits of 2-14 AWG CU-AL and 1 circuit of 300 MCM - 6 AWG CU-AL.
How many circuits does the CGK Junction/Pull Box support?
The CGK Junction/Pull Box supports 3 circuits with wire sizes from 4 to 14 AWG CU-AL.
