NSI Industries DE703 - Copper Solderless Lug 10-14 AWG Made of 99.98 pure electrolytic copper. Steel-plated screws to prevent rusting. 25 to 70 ampere size have slotted head screws. Larger sizes have hex head screws. Rated 600 volts max. UL 486 Listed. Temperature rating 90 degrees C.
NSI Industries

DE703

UPC: 662381005106

Documents & Media
Technical Bulletin

Contact for Pricing

Overview

The NSI Industries DE703 is a high-quality copper solderless lug designed for reliable electrical connections. Constructed from 99.98% pure electrolytic copper, this lug ensures excellent conductivity and durability. It is specifically engineered for use with copper wire, accommodating a wire range of 10-14 AWG. The DE703 features steel-plated screws, a critical component for preventing rust and maintaining connection integrity over time. For the 25 to 70 ampere sizes, slotted head screws are utilized, while larger sizes incorporate hex head screws for enhanced torque application. This lug is rated for a maximum of 600 volts, making it suitable for a wide range of industrial and commercial applications. Its robust construction is further validated by its UL 486 Listed certification, assuring compliance with stringent safety and performance standards. The temperature rating for the DE703 is 90 degrees Celsius, allowing for operation in moderate to high-temperature environments. The SKU for this product is DE703, and it is manufactured by NSI Industries, a trusted name in electrical connectors. The lug's dimensions include a length of 1.025 inches, a width of 0.315 inches, and a height of 0.465 inches, with a tang length of 0.195 inches and a tang thickness of 0.069 inches. The mounting hole diameter is 0.160 inches, and it uses a 1/4" mounting bolt. The maximum torque value is 60 in./lbs. This lug is supplied in standard cartons of 100 units. Its UNSPSC code is 39121405, and it is proudly made in the USA. Choose the NSI DE703 for secure, long-lasting solderless connections in your electrical systems.
  • Constructed from 99.98% pure electrolytic copper for superior conductivity.
  • Features steel-plated screws to prevent rusting and ensure long-term reliability.
  • Accommodates wire sizes from 10 to 14 AWG.
  • Rated for a maximum of 600 volts.
  • UL 486 Listed for safety and performance assurance.

Specifications

Amperage Rating
25 Amps
Application
NSI
Cable Size
10-14 AWG
Color
Copper
Connection Type
Solderless
Current Rating
25-70 A
Environmental Conditions
90 C
Material
99.98% pure electrolytic copper
Material
Copper
Number Of Holes
1
Size
L=1.025 - H=.195 - W=.315 IN
Size
10-14 AWG
Special Features
10-14 AWG - CU Only - 100 Pack
Standard
UL486B
Type
Copper Single Lug
Voltage Rating
600 V
Warranty
1 Year
Package Dimensions (L x W x H)
1.025 IN x 0.315 IN x 0.465 IN
Package Dimensions (L x W x H)
2.6035 cm x 8.001 mm x 11.811 mm
Package Weight (Imperial)
1.300 L
Package Weight (Metric)
0.590 kg
