ABB - Installation Products LRT 33 UX - Aluminum Universal Quick Disconnect Transformer Connectors - LRT-UX Series, fully insulated, cable range 12-350, length 4 in, height 4-3/8 in, stud size 5/8 & 1, outlets 6

ABB Installation Products LRT 33 UX Aluminum Universal Quick Disconnect Transformer Connectors - LRT-UX Series, fully…

UPC: 783786738243

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 24

Multiplier: 24

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB LRT 33 UX is a fully insulated aluminum universal quick disconnect transformer connector from the LRT-UX Series. Engineered for reliable electrical connections, this connector is designed to accommodate a cable range from 12 AWG to 350 kcmil, offering significant flexibility for various power distribution needs. Its compact dimensions, with a length of 4 inches and a height of 4-3/8 inches, facilitate installation in confined spaces. The LRT 33 UX features multiple outlets, specifically 6, allowing for efficient multi-point connections. It is compatible with stud sizes of 5/8 inch and 1 inch, ensuring broad applicability with standard transformer terminals. This connector is manufactured by ABB - Installation Products, a recognized name in electrical components. Its construction and design prioritize safety and operational efficiency in transformer applications. The universal nature of the LRT 33 UX simplifies inventory and application, reducing the need for specialized connectors. This product is essential for secure and quick connections in electrical systems where transformers are utilized, ensuring proper power flow and system integrity. The LRT 33 UX supports efficient maintenance and upgrades due to its quick disconnect functionality.
  • Fully insulated aluminum construction for safety and conductivity
  • Universal design accommodates cable sizes from 12 AWG to 350 kcmil
  • Features 6 outlets for versatile multi-point connections
  • Compatible with 5/8 inch and 1 inch stud sizes
  • Compact dimensions: 4 in length, 4-3/8 in height

Specifications

Application
Transformer Connection
Conductor Range
#12 to 350 kcmil
Connection
Mechanical
Insulation
Clear Cover
Material
Aluminum
Number of Conductors
6
Poles
6
Series
LRT-UX Series
Size
4 inch X 4-3/8 inch
Size
4 in (length), 4-3/8 in (height)
Special Features
Compact Design halves Cantilever Stress and Doubles cable capacity, lessening the occurrence of leaky bushings. Clear Deadfront insulator for safe and time-saving installations and disconnects, locks in place by raised set screws or installation of first conductor
Type
Quick-Disconnect Transformer Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.0000 L
Package Weight (Metric)
0.4540 kg
