ABB - Installation Products LRT 44 U - Aluminum Universal Quick Disconnect Transformer Connectors - LRT-U Series, bare bar, cable range 12-350, length 4 in, height 2-1/2 in, stud size 5/8 & 1, outlets 8

ABB Installation Products LRT 44 U Aluminum Universal Quick Disconnect Transformer Connectors - LRT-U Series, bare bar…

UPC: 783786738274


Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 60

Multiplier: 60

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB LRT 44 U is a universal quick disconnect transformer connector designed for reliable electrical connections in industrial and commercial applications. Part of the LRT-U Series, this bare bar connector supports cable ranges from 12 AWG to 350 kcmil, making it suitable for heavy-duty power distribution systems. With a compact 4-inch length and 2.5-inch height, it fits standard enclosures and panels while providing eight outlets for flexible wiring configurations. The connector features 5/8" and 1" stud sizes to accommodate various terminal types, ensuring compatibility with a wide range of transformer and distribution equipment. Ideal for transformer secondary connections, panelboards, and switchgear, the LRT 44 U delivers fast, secure disconnection without tools, reducing downtime during maintenance or upgrades. Its aluminum construction ensures lightweight durability and corrosion resistance in harsh environments. Trusted by engineers for its precision engineering and adherence to industry standards, the LRT 44 U is a cost-effective solution for high-current applications where reliability and ease of use are critical.
  • Universal quick disconnect design for fast, tool-free connections
  • Supports cable ranges from 12 AWG to 350 kcmil
  • Compact 4" length and 2.5" height for space-constrained installations
  • Eight outlets with 5/8" and 1" stud sizes for versatile compatibility
  • Aluminum construction for lightweight durability and corrosion resistance

Specifications

Application
Transformer Connection
Conductor Range
#12 to 350 kcmil
Connection
Mechanical
Insulation
False
Material
Aluminum
Number of Conductors
8
Size
4 inch x 2-1/2 inch
Special Features
Compact Design halves Cantilever Stress and Doubles cable capacity, lessening the occurrence of leaky bushings
Type
Stud-Mount Transformer Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.0000 L
Package Weight (Metric)
0.4540 kg
Multi Seal, Aluminum Insulated Bus Connector, #12 Solid - 350 kcmil, Aluminum and Copper, Four Conductor. Outward Rocket.

RAB 4 OR

Multi Seal, Aluminum Insulated Bus Connector, #12 Solid - 350 kcmil, Aluminum and Copper, Four Conductor. Outward Rocket.
Aluminum Universal Quick Disconnect Transformer Connectors - LRT-UX Series, fully insulated, cable range 12-350, length 4 in, height 4-3/8 in, stud size 5/8 & 1, outlets 8

LRT 44 UX

Aluminum Universal Quick Disconnect Transformer Connectors - LRT-UX Series, fully insulated, cable range 12-350, length 4 in, height 4-3/8 in, stud size 5/8 & 1, outlets 8
Quick Disconnect Transformer, 5 Positions, 12-350 MCM With Cover. Connector Length 6.937 inches x 1.375 inch wide x 1.500 inch high

LRT 5350-1

Quick Disconnect Transformer, 5 Positions, 12-350 MCM With Cover. Connector Length 6.937 inches x 1.375 inch wide x 1.500 inch high
Quick Disconnect Transformer, 5 Positions, Compound, 12-350 MCM With Cover. Connector Length 6.937 inches x 1.375 inch wide x 1.500 inch high

LRT 5350-1 C

Quick Disconnect Transformer, 5 Positions, Compound, 12-350 MCM With Cover. Connector Length 6.937 inches x 1.375 inch wide x 1.500 inch high
Aluminum Connector with Clear Insulating Boot (CBB3344) Aluminum Quick Disconnect Transformer Connector, Uninsulated, 8 Outlets, Conductor 500, Oxide Inhibitor, Street Light option, Black Cap - 600 Side, Pink Cap - 1/0 side. Eight (8) Screws. Connector 4.062 inch long x 2.500 inch high. Cover Inside Dimensions 4.031 inch long, 3.312 inch wide, 4.250 inch High

LRT50044USSLCCBB3344

Aluminum Connector with Clear Insulating Boot (CBB3344) Aluminum Quick Disconnect Transformer Connector, Uninsulated, 8 Outlets, Conductor 500, Oxide Inhibitor, Street Light option, Black Cap - 600 Side, Pink Cap - 1/0 side. Eight (8) Screws. Connector 4.062 inch long x 2.500 inch high. Cover Inside Dimensions 4.031 inch long, 3.312 inch wide, 4.250 inch High
Aluminum Quick Disconnect Transformer Connectors - LRT Series, wire range 12-350, insulator length 10-1/4, outlet 6

LRT 6350

Aluminum Quick Disconnect Transformer Connectors - LRT Series, wire range 12-350, insulator length 10-1/4, outlet 6
Stud Adapter Threaded Transformer Connector. Adapter with Inter Stud Size 5/8-11 UNC-2B - Right Hand Thread and Outer Stud Size 1-14 UNS-2A Left Hand Thread, Pink Cap, TL 101 Grease.

2135 STUD ADAPTER

Stud Adapter Threaded Transformer Connector. Adapter with Inter Stud Size 5/8-11 UNC-2B - Right Hand Thread and Outer Stud Size 1-14 UNS-2A Left Hand Thread, Pink Cap, TL 101 Grease.
Aluminum Quick Disconnect Transformer Connectors - LRT Series, wire range 12-350, Connector Length 10.577 inches, outlet 8, with Streetlight-Outlet Option and Oxide Inhibitor

LRT 8350 SLC

Aluminum Quick Disconnect Transformer Connectors - LRT Series, wire range 12-350, Connector Length 10.577 inches, outlet 8, with Streetlight-Outlet Option and Oxide Inhibitor

Frequently Asked Questions

How many outlets does the LRT 44 U have?

The LRT 44 U features eight outlets for flexible wiring configurations.

What cable sizes does the LRT 44 U support?

The LRT 44 U supports cable ranges from 12 AWG to 350 kcmil, making it suitable for heavy-duty applications.

What are the stud sizes on the LRT 44 U?

The LRT 44 U includes 5/8" and 1" stud sizes to accommodate various terminal types.

Can the LRT 44 U be used with transformers?

Yes, the LRT 44 U is designed for transformer secondary connections and high-current applications.

Is the LRT 44 U suitable for outdoor use?

The aluminum construction of the LRT 44 U provides corrosion resistance, making it suitable for harsh environments.
