ABB - Installation Products AMTD7502508 - AMT 8 Port Both Sides PVC Connector, Ultraviolet Resistant, Wire Range 750-250 kcmil, Length 11.44 Inches, Width 3.13 Inches, Height 2.38 Inches, Hex Size 3/8 Inch, Black Insulation

ABB Installation Products AMTD7502508 AMT 8 Port Both Sides PVC Connector, Ultraviolet Resistant, Wire Range 750-250 kcmil…

UPC: 783786810529

Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB AMT 8 Port Connector, identified by SKU AMTD7502508, is a high-performance electrical connection component engineered for demanding industrial environments. Constructed from a durable, ultraviolet-resistant PVC material, this connector is built to withstand prolonged exposure to sunlight and harsh environmental conditions, ensuring sustained operational integrity and a long service life. The design features an 8-port configuration, with connection points available on both sides of the unit, which significantly enhances wiring efficiency and simplifies complex electrical layouts. This versatile connector is specifically designed to accept a broad range of wire sizes, accommodating conductors from 750 kcmil down to 250 kcmil, thereby offering flexibility for diverse project requirements and conductor types. The physical dimensions of the connector are substantial, measuring 11.44 inches in length, 3.13 inches in width, and 2.38 inches in height, providing ample internal volume for secure and reliable wire termination and connection. Installation is facilitated by a standard 3/8 inch hex size requirement for the necessary tools. The connector is finished in a black insulation color, which is a common practice in electrical systems for aiding in circuit identification and adhering to established electrical color coding conventions. This ABB AMT connector is an optimal choice for applications necessitating secure, multi-conductor splices and taps, particularly where resistance to environmental factors is a critical performance criterion. Its construction and design emphasize straightforward installation procedures and the delivery of dependable electrical continuity, making it suitable for critical power distribution systems. The product's UNSPSC code is 39121428.
  • 8-pole configuration with connections on both sides
  • Constructed from ultraviolet-resistant PVC for durability
  • Accommodates wire ranges from 750 kcmil to 250 kcmil
  • Dimensions: 11.44" L x 3.13" W x 2.38" H
  • Requires 3/8" hex size for installation

Specifications

Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
4.0700 L
Package Weight (Metric)
1.8460 kg
