ABB Installation Products ADR6004-3 Type ADR-ALCUL Single-Conductor, One-Hole Mount for Conductor Range Max 600 kcmil (2)…
UPC: 783786349715
Documents & Media
Contact for Pricing
Minimum Qty: 30
Multiplier: 30
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Single-conductor, one-hole mount design for simplified installation
- Supports conductor ranges from 4 AWG stranded to 600 kcmil
- Compatible with (2) 250 kcmil or (2) 1/0 AWG stranded conductors
- Optimized for high-current environments in power distribution and motor control
- Part of ABB’s Installation Products line for industrial electrical systems
Specifications
Bolt Size | 3/8 in |
Connection Type | One-Hole Mount |
Finish | Tinned |
Material | Aluminum |
Mounting Type | One-hole mount |
Number of Conductors | 1 |
Number of Mounting Holes | 1 |
Poles | 1 |
Series | ADR-ALCUL |
Size | Conductor Range Max 600 kcmil (2) 250 kcmil, Min 4 Str. (2) 1/0 Str. |
Size | Max 600 kcmil, Min 4 AWG |
Special Features | Easy Installation - no special tools required |
Type | Dual-Rated Mechanical Connector |
Package Dimensions (L x W x H) | 7.25 IN x 6.5 IN x 4 IN |
Package Dimensions (L x W x H) | 18.415 cm x 16.51 cm x 10.16 cm |
Package Weight (Imperial) | 0.7600 L |
Package Weight (Metric) | 0.3450 kg |
TS350-2
2 Port Aluminum Dual Rated Transformer Stud Connector 350 MCM -6 AWG with 5/8" Stud Aluminum dual rated transformer stud connectors are versatile and reusable set screw connectors made from 6061T-6 aluminum alloy for superior electrical and mechanical performance. Clear plated for low contact resistance- stud is tin plated copper which provides low contact resistance for connection to transformer. For use with copper and aluminum conductors. Meets or exceeds ANSI C119.4 Class A. Rated 600V. Temperature rating 90 degrees C.
PCSB4-3S-12Y
The PCSB4-3S-12Y Multi-Tap Mechanical Lug has a flexible design that can be used as a tap, splice, or dead-end Lug. Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance. Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion. UL Listed and CSA Certified.
IPC1102
Type IPC - Talon Insulation Piercing Connector for Conductor Range Main: 1/0-8 AWG, 50-6 MM sq., Tap: 2-8 AWG, 35-6 MM sq.
ADR35AR
Type ADR-ALCUL Anti-Rotational Single-Conductor, One-Hole Mount, Conductor Range Max 350 MCM, Min 6 AWG, 5/16 Inch Bolt Hole, Tin Plated
STC0614
Type STC - Copper Single-Conductor, One-Hole Mount (Straight Tang), Conductor Range 14 AWG-6 Str, Length 1-9/64 Inches, Width 3/8 Inch, Height 11/16 InchSTC4102
Type STC - Copper Single-Conductor, One Hole Mount (Straight Tang) for Conductor Range 2 Str.-4/0 Str.Frequently Asked Questions
What is the UNSPSC code for this product?
The UNSPSC code for the ADR6004-3 is 39121408, classifying it as an electrical installation product.
What conductor sizes does this mount support?
The ADR6004-3 supports conductor sizes from a minimum of 4 AWG stranded to a maximum of 600 kcmil.
What is the mounting type for this connector?
The ADR6004-3 features a single-conductor, one-hole mount design for secure installation.
How many conductors can this mount accommodate?
The device accommodates up to two conductors, such as (2) 250 kcmil or (2) 1/0 AWG stranded conductors.
Is this product suitable for high-current applications?
Yes, the ADR6004-3 is designed for high-current environments, supporting conductor sizes up to 600 kcmil.
How to Install Blackburn Aluminum Dual Rated Connectors
This guide provides step-by-step instructions for safely installing Blackburn Aluminum Dual Rated Connectors with aluminum or copper conductors, including conductor preparation, insertion, and proper torque application for both setscrews and mounting hardware.
Estimated time: 15m
Tools needed:
Wire strippers, Wire brush, Torque wrench
Supplies needed:
Blackburn Contax Type CT or Weaver Type CP oxide inhibiting compound, Aluminum Dual Rated Connector, Conductors (aluminum, copper-clad aluminum, or copper), Mounting hardware, Flat washers (optional), Belleville washers (optional)
- Verify Conductor and Connector Size
CAUTION: De-energize before installing connectors. Check the conductor size marked on the connector to ensure it is the correct connector for the conductor size you intend to use.
- Strip Conductor Insulation
Carefully strip the conductor insulation to the length of the connector barrel, avoiding any damage to the conductor strands during the process.
- Prepare and Insert Conductor
Wire brush the conductor thoroughly. If using an aluminum conductor, apply Blackburn Contax Type CT or Weaver Type CP oxide inhibiting compound. Fully insert the prepared conductor into the connector and wipe off any excess oxide inhibitor.
- Torque Connector Setscrew
Identify the maximum conductor size the connector accommodates. Apply the recommended tightening torque to the setscrew in accordance with TABLE 1 (refer to the original documentation for specific values) to ensure a secure connection.
- Apply Oxide Inhibitor to Contact Surface
Prior to mounting the connector, apply Blackburn Contax Type CT or Weaver Type CP oxide inhibiting compound to the flat contact surface of the connector.
- Torque Mounting Hardware
Install the mounting hardware. Torque the mounting hardware to the values shown in TABLE 2 (refer to the original documentation for specific values). For best installation practice, use flat and Belleville washers in conjunction with the mounting hardware, although the connectors will perform satisfactorily without them.
