Overview
- Energy-efficient rotary compressor
- R513A or R134a refrigerant
- Reliable Smart Controller on enclosure side of the unit
- 10-degree sloped top shroud, welded and ground
- Sloped internal surfaces reduce catchpoints for water, dust, bacteria build-up
- FDA-approved neoprene gasket
- No louvers on vertical surfaces allow washdown with minimal protections
- Cutout Adapter options for enclosures with older nVent HOFFMAN or Competitive units for easy transitions to new air conditioners
- Cleanable, reusable aluminum mesh filter included to protect coils for maximum cooling performance in dirty environments
- UL Listed to save customers time and money with agency approvals
Specifications
Application | Controls and Drives; Power Distribution; Corrosive Environments |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Color | Unpainted |
Depth | 346 mm |
Depth | 13.64 in |
Finish | Brushed #4 |
Frequency | 50-60 Hz |
Height | 566 mm |
Height | 22.29 in |
Material | SS304 |
Material | Stainless Steel 304 |
Max Current | 6.3 A |
Nominal Capacity Btu/h | 2,300 Btu/h |
Nominal Capacity Watts | 675 W |
Nominal Voltage | 115 V |
Number Of Phases | 1 |
Operating Temperature | 55 °C |
Operating Temperature | 131 |
Operating Temperature | 55 |
Product Family | Extreme Environments |
Protection Rating | NEMA Type 12 |
Refrigerant | R134a |
Remote Access Control | Yes |
Series | X2 |
Size | 22.29x10.23x13.64 |
Type | Air Conditioners |
Voltage Rating | 115 V |
Weight | 65 lb |
Width | 10.23 in |
Width | 260 mm |
Package Dimensions (L x W x H) | 18 IN x 13.63 IN x 24.94 IN |
Package Dimensions (L x W x H) | 45.72 cm x 34.6202 cm x 63.3476 cm |
Package Weight (Imperial) | 79.000 L |
Package Weight (Metric) | 35.834 kg |
How to Install the X230226G160 Air Conditioner
This guide provides step-by-step instructions for installing the X230226G160 air conditioner, ensuring proper mounting, wiring, and initial setup.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Gasket kit, Washers
- Inspect the air conditioner
Check the air conditioner for any visible damage and verify its functionality by connecting it to a properly grounded power supply. Operate the unit for 5 to 10 minutes to ensure it runs without excessive noise or vibration.
- Prepare the mounting area
Using the cutout dimensions provided in the manual, prepare the opening and bolt hole pattern on the enclosure for mounting the air conditioner.
- Install the gaskets
Apply the gaskets from the gasket kit to the enclosure, aligning them with the prepared cutout and bolt hole pattern.
- Mount the air conditioner
Secure the air conditioner to the enclosure using the provided mounting bolts and washers. Torque the bolts to 22.5 in-lb (2.5 Nm) and ensure the unit remains upright for at least five minutes before starting.
- Connect the power supply
Refer to the nameplate for the electrical requirements and connect the power supply to the air conditioner. Ensure the circuit is properly fused and avoid using an extension cord.
- Configure the smart controller
Access the smart controller settings by entering the passcode. Review and adjust the cooling/heating setpoints and alarm parameters as necessary.
- Test the installation
After completing the installation and configuration, run the air conditioner to verify that it operates correctly and that all settings are functioning as intended.
