nVent WS161208SS WaterShed Wallmount Sloped Top 1/4-Turn Latch Type 4X, 16x12x8, Brushed, SS 304
UPC: 783510130886
Documents & Media
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Seams continuously welded and ground smooth
- Smooth Type 304 stainless steel lift-off bullet-style hinges
- Hinges are shielded by door
- Hinged side of door has provisions to allow direct flushing of hinge area
- 20-degree sloped top facilitates runoff of water and cleaning solutions and prohibits the placement of objects on the top of the enclosure
- 97-degree door opening
- Door edges are sloped 20-degrees at top and bottom edges to facilitate runoff
- Slanted flange trough collar prohibits pooling of fluids along the top edge of the enclosure opening
- Stainless steel quarter-turn latches furnished with flush slotted insert
- Seamless foam-in-place gasket
Specifications
Application | Controls and Drives; Hygienic Environments; Corrosive Environments |
Application | Controls and Drives;Corrosive Environments;Hygienic Environments |
Color | Unpainted |
Color | Brushed |
Conductive Panel | A16P12G |
Depth | 203 mm |
Depth | 8 in |
Depth | 8 mm |
Finish | Brushed #4 |
Height | 406 mm |
Height | 16 in |
IP Rating | IP66 |
Latch Quantity | 2 |
Material | Stainless Steel 304 |
Material | SS 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Wallmount |
Nema Rating | Type 4X |
NEMA Rating | 4X |
NEMA Rating | 4X Watertight, corrosion-resistant |
Panel | A16P12 |
Product Family | WaterShed |
Protection Rating | NEMA Type 12 |
Series | WaterShed |
Size | 16.00x12.00x8.00 in |
Size | 16X12X8 |
Stainless Steel Panel | A16P12SS6 |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Stainless Steel Wall Mounted Industrial Enclosures |
Type | Hazardous Location Enclosures |
Type Number | Type 3R |
Weight | 25 lb |
Width | 305 mm |
Width | 12 IN |
Package Dimensions (L x W x H) | 24.75 IN x 13.25 IN x 10.25 IN |
Package Dimensions (L x W x H) | 62.865 cm x 33.655 cm x 26.035 cm |
Package Weight (Imperial) | 25.000 L |
Package Weight (Metric) | 11.340 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
Frequently Asked Questions
What are the dimensions of the WS161208SS enclosure?
The enclosure measures 16 inches in width, 12 inches in height, and 8 inches in depth.
What material is the WS161208SS made from?
The enclosure is constructed from 14-gauge Type 304 stainless steel with a #4 brushed finish.
What type of latch does the WS161208SS use?
The enclosure features stainless steel quarter-turn latches with flush slotted inserts for secure closure.
Does the WS161208SS have a sloped top?
Yes, the enclosure has a 20-degree sloped top to facilitate water runoff and prevent contaminant collection.
What certifications does the WS161208SS have?
The enclosure is UL 508A Listed (Type 4, 4X, 12) and cUL Listed per CSA C22.2 No. 94.
Can the WS161208SS be mounted directly to a wall?
Yes, the enclosure includes mounting holes in the back for direct wall mounting.
What is the gauge of the stainless steel used in the WS161208SS?
The enclosure is constructed from 14-gauge Type 304 stainless steel.
Does the WS161208SS have a grounding provision?
Yes, the enclosure includes a door bonding provision and a body grounding stud.
How to Install the WS161208SS Wall-Mount Enclosure
Instructions for mounting and securing the WS161208SS wall-mount enclosure to a surface.
Estimated time: 30m
Tools needed:
Screwdriver, Drill (if needed for mounting surface), Level
Supplies needed:
Customer-supplied 3/8 inch or M8 fasteners, Flat washers, Nuts, Sealing washers (provided), Silicon rubber sealant (optional, for NSF certification)
- Prepare the mounting location
Ensure the mounting surface is flat and stable. If required for NSF certification, plan to apply silicon rubber sealant around the perimeter where the enclosure will mount.
- Mount the enclosure
Use the mounting holes provided in the back of the enclosure. Attach the enclosure to the wall or structure using customer-supplied 3/8 inch or M8 fasteners, flat washers, and nuts. Install the provided sealing washers inside the enclosure with the rubber face against the enclosure body to ensure proper sealing and protection rating. Ensure the enclosure is level.
- Apply sealant (if applicable)
If maintaining NSF certification, apply silicon rubber sealant to the perimeter between the enclosure back and the mounting surface before final tightening of fasteners.
- Verify mounting security
Ensure all fasteners are securely tightened and the enclosure is firmly attached to the mounting surface.
