Overview
- Description: Front and rear plinth sections with ventilated panels. Recommended to be used in combination with the ventilated bottom plate CVB. For cabling without any restrictions and in accordance with the VDE 0113 standard. The plinth consists of four
- Material: Corner pieces in 2 mm and panels in 1.5 mm mild steel.
- Finish: RAL 7022 structured powder coating.
- Pack quantity: 1 set of 4 corner pieces including covers. Front and rear panel with mounting accessories for side panels PS or transversal profiles PCP.
- Mounting requirements: Add the side panels PS for a complete plinth. When combining enclosures it is recommended to add transversal panels PCP for cable duct support and extra rigidity. Use ventilated bottom plates CVB to get better enclosure ventilation.
- Mounting requirements: add the side panels PS for a complete plinth; when combining enclosures it is recommended to add transversal panels PCP for cable duct support and extra rigidity; use ventilated bottom plates CVB to get better enclosure ventilation
Specifications
Application | Controls and Drives;Factory Automation and Process Control;Power Distribution |
Application | Controls and Drives; Factory Automation and Process Control |
Color | Umbra Gray |
Color | Gray;RAL 7022 Gray |
Color | RAL 7022 |
Color Code | RAL 7022 |
Construction | 16 gauge |
Depth | 62 mm |
Depth | 2.44 |
Depth | 62 |
Enclosure Material | Mild Steel |
Finish | Powder Coated |
Finish | Powder Coating |
Height | 100 mm |
Height | 3.94 |
Height | 100 |
Material | Mild Steel |
Mounting Type | Floor-standing |
Package Quantity | 2 |
Product Family | Free-Standing |
Series | PV |
Size | 100x998x62mm |
Size | 3.94 x 39.29 x 2.44 inch |
Thickness | 51.40mm (2.024") |
Thickness | 1.5 mm |
Thickness | 16 ga |
Type | Fixing |
Type | IEC Enclosure Accessories |
Weight | 11.8 lb |
Weight | 32 lbs./100ft |
Width | 39.29 |
Width | 998 |
Width | 39.37 in |
Width | 1,000 mm |
Works With | IEC |
Package Dimensions (L x W x H) | 39.75 IN x 1 IN x 40 IN |
Package Dimensions (L x W x H) | 100.965 cm x 2.54 cm x 101.6 cm |
Package Weight (Imperial) | 11.800 L |
Package Weight (Metric) | 5.353 kg |
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Mount PF/PV/PS Series Components
This guide outlines the general mounting procedure for PF/PV/PS series components, focusing on bolt sizes and torque specifications for secure installation.
Estimated time: 30m
Tools needed:
SW19 wrench, SW8 wrench, T40 Torx wrench
Supplies needed:
M12 bolts, M8x16 bolts
- Secure Main Component with M12 Bolts
Using a SW19 wrench, secure the main component at two designated points with M12 bolts. Apply a torque of 15-20 Nm to each bolt to ensure a firm attachment.
- Attach Secondary Component with M8x16 Bolts
Utilize an SW8 wrench to attach the secondary component using 4 to 8 M8x16 bolts. Tighten these bolts to a torque of 10-15 Nm.
- Fasten Additional M12 Connections
For any remaining M12 or M12x20 connections, use a SW19 wrench and apply a torque of 15-20 Nm. Ensure all connections are secure according to the specifications.
