Overview
- Material: Frame: 1.5 mm painted steel. Doors: 2 mm painted steel. Rear, roof and side panels: 1.5 mm painted steel. Mounting plate: 3 mm galvanized steel. Bottom plates: 1 mm galvanized steel.
- Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660. Including integrated external hole pattern.
- Doors: Mounted with four hinges. Including door frame with 25 mm hole pattern. Doors cannot be reversed. Separate doors to be ordered for left hand door locking.
- Rear panel: Fitted by M6 torx screws. Standard facilities for rear doors mounting. Split rear panels in 1600 mm wide enclosures. RD version comes with rear door instead of rear panel.
- Side panels: Supplied as an accessory.
- Roof panel: Removable.
- Lock: Espagnolette 4-point locking system in the main door and 2-point locking system in the slave door. Standard double-bit lock with 3 mm insert. Standard inserts, cylinders, lift handles and T-handles are available as accessories.
- Bottom plates: Consists of three or four (D>600) pieces.
- Mounting plate: Double folded and slides into position. Adjustable in depth by steps of 25 mm, with the MPD02 accessory. Supplied, attached on the outside of the enclosure packaging.
- Earthing: All panels are earthed through their fittings and equipped with a separate earthing stud.
Specifications
Application | Factory Automation and Process Control; Controls and Drives |
Application | Controls and Drives;Factory Automation and Process Control |
Body Thickness | 1.5 mm |
Body Thickness | 16 ga |
Cable Entry | No |
Color | Gray |
Color | Grey |
Color | Light Gray |
Color Code | RAL 7035 |
Construction | Body: 16 gauge Door: 14 gauge |
Depth | 400 mm |
Depth | 15.75 |
Depth | 400 |
Door Thickness | 14 ga |
Finish | Powder Coated |
Finish | Powder Coating |
Height | 78.74 |
Height | 2,000 |
Height | 2,000 mm |
IP Rating | IP55 |
Material | Mild Steel |
Max Mounting Depth | 11.1 in |
Max Mounting Depth | 14.13 in |
Mounting | Free Standing |
Mounting Plate Height | 1,894;74.57 mm;mm |
Mounting Plate Included | Yes |
Mounting Plate Width | 58.82 in |
NEMA Rating | 12 |
NEMA Rating | NEMA Type 12 |
Protection Rating | NEMA Type 12 |
Rear Door Included | No |
Rear Panel Included | Yes |
Series | MCD |
Size | 2000x1600x400mm |
Size | 78.74 x 62.99 x 15.75 inch |
Type | Mild Steel Modular Industrial Enclosures |
Weight | 639.6 lb |
Width | 62.99 |
Width | 1,600 |
Width | 1,600 mm |
Package Dimensions (L x W x H) | 79.12 IN x 63.37 IN x 63.62 IN |
Package Dimensions (L x W x H) | 200.9648 cm x 160.9598 cm x 161.5948 cm |
Package Weight (Imperial) | 639.600 L |
Package Weight (Metric) | 290.123 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
How to Install the MCS20085R5 Controller
This guide provides step-by-step instructions for installing and configuring the MCS20085R5 Controller, ensuring proper mounting, wiring, and initial setup.
Estimated time: 1h
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors, Floor plate (if required)
- Mount the controller
Secure the MCS20085R5 Controller to the designated mounting surface using the provided mounting screws. Ensure the controller is level and firmly attached.
- Connect the wiring
Use wire connectors to connect the power and signal wires to the appropriate terminals on the controller. Ensure all connections are secure and insulated.
- Verify the installation
Use a multimeter to check the voltage at the controller terminals to ensure proper power supply. Confirm that all connections are correct and secure.
- Configure the controller settings
Access the controller's configuration interface and input the necessary parameters for operation. Follow the manufacturer's guidelines for specific settings.
- Calibrate the controller
Perform any required calibration procedures as outlined in the user manual to ensure optimal performance of the MCS20085R5 Controller.
