Contact for Pricing
Overview
- Mounting hardware included
- Designed for 250mm enclosure dimensions (A or B)
- Supports DIN rail or direct panel mounting
- Offset design provides extra clearance for cables and ventilation
- Manufactured by nVent for reliable performance
Specifications
Application | Controls and Drives |
Color | Unpainted |
Finish | Zinc Plated |
Fits Height | 2000 mm mm |
Fits InLine Enclosure | When A or B = 250 mm |
Hole Quantity | 13 |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Product Family | InLine |
Size | fits 250mm |
Thickness | 2.66 mm |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | Industrial Panels and Panel Accessories |
Weight | 0.7 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 10.25 IN x 8 IN x 0.5 IN |
Package Dimensions (L x W x H) | 26.035 cm x 20.32 cm x 1.27 cm |
Package Weight (Imperial) | 0.700 L |
Package Weight (Metric) | 0.318 kg |
How to Install the LMK23 Controller
This guide provides step-by-step instructions for installing and configuring the LMK23 Controller for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors
- Mount the controller
Secure the LMK23 Controller to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the power supply
Using wire connectors, connect the power supply wires to the designated terminals on the LMK23 Controller. Verify that the connections are secure and insulated.
- Configure initial settings
Power on the LMK23 Controller and use the interface to navigate to the settings menu. Set the required parameters according to your application needs.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure the LMK23 Controller is accurately measuring and responding to inputs.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
