Overview
- Protects filter fan and exhaust grill from wind-driven rain and high-pressure hose water
- Easy one person installation with simple back panel mounting
- Easily accessed filter simplifies replacement
- Low-profile design (10.50 x 8.00 x 1.85 in) minimizes enclosure footprint
- Compatible with nVent HF04/HF05 filter fans and HG04/HG05 exhaust grilles
Specifications
Application | Controls and Drives;Power Distribution |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 47 mm |
Depth | 1.85 in |
Finish | Powder Coated |
Height | 10.5 in |
Height | 267 mm |
Material | Steel |
Material | Galvanized Steel with RAL 7035 Light Gray Polyester Powder Coat |
Material | Mild Steel |
Mounting Type | Back Panel Mounting |
NEMA Rating | Type 3R |
Nema Rating | Type 3R, Type 12 |
Protection Rating | NEMA Type 3R |
Series | HH05 |
Size | 10.50x8.00x1.85 |
Size | 10.50x8.00x1.85 in |
Thickness | 1.52 mm |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | Fans and Filter Fans |
Weight | 3.9 lb |
Width | 203 mm |
Width | 8 in |
Package Dimensions (L x W x H) | 12 IN x 9.6 IN x 4.5 IN |
Package Dimensions (L x W x H) | 30.48 cm x 24.384 cm x 11.43 cm |
Package Weight (Imperial) | 3.900 L |
Package Weight (Metric) | 1.769 kg |
How to Install the HH05GS35001 Filter Fan Shroud
This guide provides step-by-step instructions for installing the HH05GS35001 filter fan shroud to ensure proper ventilation and maintain the UL/cUL Type 3R rating.
Estimated time: 30m
Tools needed:
Screwdriver, Wire strippers
Supplies needed:
Mounting screws, Gasket
- Prepare the installation area
Ensure the installation area is clean and free of debris. Verify that the mounting surface is level and suitable for the shroud.
- Mount the filter fan shroud
Align the shroud with the mounting holes and secure it using the provided mounting screws. Ensure it is firmly attached and level.
- Install the gasket
Place the gasket around the edges of the shroud to ensure a proper seal. This will help maintain the Type 3R rating.
- Connect the filter fan
Follow the wiring diagram to connect the filter fan to the power supply. Use wire strippers to prepare the wires and ensure secure connections.
- Verify installation
Check all connections and ensure the shroud is securely mounted. Power on the system and verify that the fan operates correctly.
