nVent DBL242412G - L-Box Type 1, 24.00x24.00x12.00, Lt Gray, Steel

nVent DBL242412G L-Box Type 1, 24.00x24.00x12.00, Lt Gray, Steel

UPC: 783510143732


Documents & Media
Installation Instructions

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The nVent L-Box Type 1 Cabinet (SKU: DBL242412G) is a 24.00 x 24.00 x 12.34 inch (610 x 610 x 313 mm) enclosure made from light gray steel. It provides NEMA Type 1 protection for indoor public settings, securely mounting and storing network equipment, patch panels, and connectivity components. The cabinet has a 22.00 in (559 mm) height and supports 6 rack units. Designed for public spaces, it ensures equipment safety and organization with a durable steel construction.
  • Spring-loaded, self-retained hinge pins allow door removal
  • 120-degree door opening for maximum eqiupment access
  • Quarter-turn latches with key lock
  • One set of fixed rack angles is included on 24- and 36-inch (610- and 914-mm) tall models and two on 48-inch (1219-mm) tall models
  • Rack angles on 36-inch (914-mm) models can be positioned either at the top or the bottom of the cabinet
  • 36- and 48-inch (914- and 1219-mm) tall models have space for patch panel or shelf brackets
  • Knockouts for 4-inch (102-mm) fan on top and bottom of cabinet
  • Wiring knockouts (7/8 inch, 1-3/8 inch, and 3 inch) on top and bottom of cabinet & two 3-inch cable entry knockouts on back
  • Multiple cable tie-down points on back of cabinet
  • Keyhole mounting slots spaced 16.00 inch (406 mm) on center for easy cabinet mounting

Specifications

Application
Networking, Storage and Data Center
Color
Gray
Color
Grey
Color
Light Gray
Color
Lt Gray
Color Code
RAL 7035
Depth
313 mm
Depth
313
Depth
12.34 in
Finish
Powder Coating;Steel/LtGray
Finish
Powder Coated
Height
610 mm
Height
24 in
Height
610
IP Rating
IP30
Material
Steel
Material
Mild Steel;Steel
Material
Mild Steel
Modification Services
Yes
NEMA Rating
1
NEMA Rating
1 Indoor, electrical protection
NEMA Rating
Type 1
Product Family
L-Box
Protection Rating
NEMA Type 1
Rack Units
6 U
Size
24.00x24.00x12.00 inch
Thickness
1.9 mm
Thickness
14 ga
Thickness
1.9
Type
Data Networking Wall Mounted Cabinets
Type Number
Type 1
Weight
60 lb
Width
610 mm
Width
610
Width
24 IN
Package Dimensions (L x W x H)
29.25 IN x 29 IN x 18.25 IN
Package Dimensions (L x W x H)
74.295 cm x 73.66 cm x 46.355 cm
Package Weight (Imperial)
60.000 L
Package Weight (Metric)
27.216 kg
Power supply for DIN-rail

PS-60

Power supply for DIN-rail
The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.

UTP6AL1MBU

The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
CIMP-M-04xRJ45

0602000104-00

CIMP-M-04xRJ45
Symmetrical DIN rail 2m 35x15x1,5 steel z-b

50000043

Symmetrical DIN rail 2m 35x15x1,5 steel z-b
5-port Ethernet Switch

SDI-550

5-port Ethernet Switch
Enlogic by nVent G3 Metered 3-phase 22kVA/Outlets (36) C13 (12) Combo C13/C19 PDU for HPE

P59417-B21

Enlogic by nVent G3 Metered 3-phase 22kVA/Outlets (36) C13 (12) Combo C13/C19 PDU for HPE
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .

ST4803PDGM

Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
6U PERF PANEL

PPFS19010BK

6U PERF PANEL
Fiber cable ODC to SC duplex - 670mm

Fiber cable ODC SC Duplex 670mm

Fiber cable ODC to SC duplex - 670mm
HPE DL3XX Gen11 2U 2-row CMA K

P54963-B21

HPE DL3XX Gen11 2U 2-row CMA K
Cable Manager, fits 19-inch open rack, Black, Steel

ECK19H

Cable Manager, fits 19-inch open rack, Black, Steel
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL

F62ERLNSNSNM002

OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL

How to Install the DBL242412G Wall-Mount Enclosure

Instructions for installing and configuring the DBL242412G Wall-Mount Enclosure, including optional rack angle setup.

Estimated time: 30m

Tools needed:

Screwdriver, Drill, Level

Supplies needed:

Mounting screws, Wall anchors (if needed)

  1. Determine mounting location

    Choose a suitable location for the DBL242412G Wall-Mount Enclosure. Ensure the mounting surface is strong enough to support the weight of the enclosure and its contents. Check the nameplate or datasheet for specific weight information.

  2. Prepare mounting surface

    If necessary, drill pilot holes in the mounting surface. Use a level to ensure the enclosure will be mounted straight.

  3. Mount the enclosure

    Secure the DBL242412G Wall-Mount Enclosure to the mounting surface using appropriate screws and anchors. Ensure the enclosure is firmly attached.

  4. Optional: Configure rack angle (36-inch model only)

    For the 36-inch model, if desired, move the rack angle to the bottom of the enclosure. Install the extra center bracket provided to complete the optional rack angle configuration. Refer to the documentation for detailed diagrams.

  5. Optional: Remove support bracket

    If extra rack spacing is required, the support bracket can be removed. Refer to the documentation for specific instructions on removal.
