Contact for Pricing
Overview
- Type 4X-rated for corrosion, water, and dust protection per NEMA standards
- 304 stainless steel construction for durability in harsh environments
- 1/4-turn latch with streamlined, brushed finish for secure and quick access
- Compact 42x30x10mm design for space-efficient installations
- Suitable for industrial control panels, automation, and outdoor electrical enclosures
- Corner formed doors are interchangeable and easily removed by pulling clip-style hinge pins
- Provision on door (except when B = 12 inch (305mm)) for thermoplastic data pocket
- Provision on door (except when B = 12 inch (305mm)) for optional doorstop kit
- Quarter-turn latches furnished with flush slotted insert
- Seamless foam-in-place gasket
Specifications
Application | Controls and Drives;Corrosive Environments |
Application | Corrosive Environments; Controls and Drives |
Body Thickness | 1.98 mm |
Body Thickness | 14 ga |
Body Thickness | 16 ga |
Color | Unpainted |
Conductive Panel | CP4230G |
Depth | 10 IN |
Depth | 254 mm |
Door Thickness | 1.98 mm |
Door Thickness | 14 ga |
Finish | Brushed #4 |
Height | 42 mm |
Height | 1,067 mm |
IP Rating | IP66 |
Latch Quantity | 1 |
Latch Type | 3-Point |
Material | Stainless Steel 304 |
Material Quality | Stainless Steel 304 |
Material Quality | Stainless steel V2A |
Modification Services | Yes |
Mounting | Wall Mounting Brackets Available |
Mounting | 40.50 x 28.50 in |
NEMA Rating | 12 |
NEMA Rating | 12 Indoor, dust-resistant |
Panel | CP4230 |
Panel Size | 40.20 x 28.20 in |
Panel Size | 1021 x 716 mm |
Product Family | Concept |
Protection Rating | NEMA Type 3R |
Protection Rating | NEMA Type 12 |
Style | 3-Point |
Type | Stainless Steel Wall Mounted Industrial Enclosures |
Type Number | Type 3R |
Weight | 94 lb |
Width | 762 mm |
Width | 30 IN |
Package Dimensions (L x W x H) | 47 IN x 31.25 IN x 12.25 IN |
Package Dimensions (L x W x H) | 119.38 cm x 79.375 cm x 31.115 cm |
Package Weight (Imperial) | 94.000 L |
Package Weight (Metric) | 42.638 kg |
Similar Products
CSD423010SS6
Application: Controls and Drives; Corrosive Environments
Material: Stainless Steel 316L
Weight: 95 lb
You May Also Be Interested In
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
