Overview
- Constructed from durable SS316 stainless steel for superior corrosion resistance.
- Type 4X NEMA rating and IP66/IP67 ingress protection for harsh environments.
- 20x24x8 inch dimensions provide ample internal space.
- Features flush-mounted quarter-turn latches for secure and easy access.
- Brushed finish offers an attractive and professional appearance.
- Corner formed doors are interchangeable and easily removed by pulling clip-style hinge pins
- Provision on door (except when B = 12 inch (305mm)) for thermoplastic data pocket
- Provision on door (except when B = 12 inch (305mm)) for optional doorstop kit
- Quarter-turn latches furnished with flush slotted insert
- Seamless foam-in-place gasket
Specifications
Application | Controls and Drives;Corrosive Environments |
Application | Corrosive Environments; Controls and Drives |
Body Thickness | 1.59 mm |
Body Thickness | 16 ga |
Color | Brushed |
Color | Brushed Stainless |
Color | Unpainted |
Conductive Panel | CP2420G |
Depth | 203 mm |
Depth | 8 mm |
Door Thickness | 14 ga |
Door Thickness | 16 ga |
Door Thickness | 1.59 mm |
Finish | Brushed #4 |
Height | 508 mm |
Height | 20 mm |
IP Rating | IP66 |
Ip Rating | IP66/IP67 |
Latch Quantity | 1 |
Latch Type | Quarter-turn |
Material | SS316 Stainless Steel |
Material | Stainless Steel 316L |
Material | Stainless 316 | 316L SS |
Material | Stainless 316 |
Material Quality | Stainless Steel 316 |
Material Quality | Stainless Steel V4A |
Modification Services | Yes |
Mounting | 22.50 x 18.50 in |
Mounting | Wall Mounting Brackets Available |
Mounting Type | Wallmount |
NEMA Rating | 12 Indoor, dust-resistant |
NEMA Rating | 12 |
Nema Rating | Type 4X |
Panel | CP2420 |
Panel Size | 564 x 462 mm |
Panel Size | 22.20 x 18.20 in |
Product Family | Concept |
Protection Rating | NEMA Type 3R |
Protection Rating | NEMA Type 12 |
Series | Concept |
Size | 20X24X8 |
Size | 20x24x8 inch |
Style | Quarter-turn |
Type | Stainless Steel Wall Mounted Industrial Enclosures |
Type Number | Type 3R |
Weight | 32 lb |
Width | 610 mm |
Width | 24 IN |
Package Dimensions (L x W x H) | 27 IN x 24 IN x 9.88 IN |
Package Dimensions (L x W x H) | 68.58 cm x 60.96 cm x 25.0952 cm |
Package Weight (Imperial) | 32.000 L |
Package Weight (Metric) | 14.515 kg |
Similar Products
CSD20248SS
Application: Controls and Drives; Corrosive Environments
Material: Stainless Steel 304
Weight: 36 lb
CSD20208SS6
Conductive Panel: CP2020G
Mounting: 18.50 x 18.50 in
NEMA Rating: 4X Watertight, corrosion-resistant
CSD20208SS
Material: Stainless Steel 304
NEMA Rating: 4X Watertight, corrosion-resistant
Size: 20.00x20.00x8.00 in
