Contact for Pricing
Overview
- Each kit includes a handle, latch, latch rods, adjustable rod guides and all hardware
- These kits are available with a key locking handle, a non-locking handle or a padlocking handle
- Two keys are furnished with keylocking handles
- Padlock provision for added security.
- Designed for field installation on most one-door Type 12 enclosures.
Specifications
Accessory Type | Locks, Lockouts, Latches, Handles and Clamps |
Application | Controls and Drives;Power Distribution |
Color | Unpainted |
Finish | Brushed |
Handle Type | Padlock |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Field installation on one-door enclosures |
NEMA Rating | 12 Indoor, dust-resistant |
Nema Rating | Type 12 |
Opens | Either Clockwise or Counterclockwise |
Size | 3 Point (A=16to30) in |
Size | Height 16-30 (adjustable) |
Type | Industrial Door Mounting and Locks |
Weight | 3.4 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 19.4 IN x 4.5 IN x 3 IN |
Package Dimensions (L x W x H) | 49.276 cm x 11.43 cm x 7.62 cm |
Package Weight (Imperial) | 3.400 L |
Package Weight (Metric) | 1.542 kg |
How to Install the AL2A Latch Kit
This guide provides step-by-step instructions for installing the AL2A latch kit, ensuring proper mounting and functionality.
Estimated time: 1h
Tools needed:
Drill, Screwdriver, Wire strippers
Supplies needed:
Nylon washers, Handle gasket, Latch rods, Roller pin, Retaining ring
- Drill holes for the latch
Locate and drill holes in the door from the outside edges using the dimensions provided in the installation guide. Ensure that you do not drill holes for rod guides.
- Install the handle gasket
Place the nylon washers and handle gasket on the outside of the door to ensure proper sealing. This step is crucial for maintaining the integrity of the latch.
- Adjust latch rods
If the latch rod is too long, select the appropriate hole and cut the latch rods approximately 3/8 inch from the center of the hole. Confirm the hole selection before cutting to avoid mistakes.
- Secure the roller pin
Insert the roller pin into the designated hole and secure it with the retaining ring. If the gasket compression is excessive, adjust the roller pin one hole at a time until the proper compression is achieved.
- Position the latch
Use the provided washers to position the latch by spacing it in or out as required for optimal functionality.
