Contact for Pricing
Overview
- Window kits of the same size use the same interchangeable cut-out
- The gasket material on all windows is resistant to oils, cutting fluids and many other liquids
- All required hardware is furnished, along with assembly and cut- out instructions
- The clear window of the Steel and Stainless Steel Window Kit is made of .25-in. (6mm) impact-resistant polycarbonate material
- Non-Metallic Window kit are made of a single piece polycarbonate material
Specifications
Accessory Type | Window Kits |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Application | Corrosive Environments; Power Distribution; Controls and Drives |
Color | Brushed |
Color | Unpainted |
Color | Brushed stainless steel |
Cutout Size | 8.69 x 12.69 in |
Cutout Size | 221 x 322 mm |
Finish | Brushed #3 |
Ip Rating | IP66/IP67 |
IP Rating | IP66 |
Material | Stainless Steel 304 |
Material | Stainless Steel;Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Rectangular Cut-Out |
Mounting Type | Cut-out |
Mounting Type | Rectangular cutout |
Nema Rating | Type 4/4X/12 |
Nema Rating | Type 4 4X |
Series | APWK |
Series | nVent APWK Series |
Size | 9.50x13.50x0.31in |
Size | 9.50x13.50x0.31 inches |
Size | 9.50x13.50x0.31 |
Size | 9.50x13.50x.31 in |
Thickness | 1.98 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Industrial Door Mounting and Locks |
Type Number | Type 13 |
Weight | 4.6 lb |
Window Size | 11.00 x 7.00 in |
Window Size | 343 x 366 mm |
Works With | NEMA / IEC |
Package Dimensions (L x W x H) | 16.6 IN x 14 IN x 2.5 IN |
Package Dimensions (L x W x H) | 42.164 cm x 35.56 cm x 6.35 cm |
Package Weight (Imperial) | 4.600 L |
Package Weight (Metric) | 2.087 kg |
TBARHDXT
This is a box support extension for a heavy duty T-BAR box bracket (TBARHD). It is made of pre-galvanized steel with a silver finish. The listed dimensions are 3-3/4 in. height, 3-1/4 in. width, and 1/4 in. depth.
P10084C
10x8x4 Polycarbonate Enclosure NEMA 6P | Standard Hinge | Clear Lid | Integrated Locking Latch | Intergrated Mounting Flange
CR460XE2D
Enclosure Accessories. Enclosure Kits (with provision for CPT and/or pilot devices, lights).
How to Install the APWK53NF Window Kit
This guide provides step-by-step instructions for installing the APWK53NF window kit, ensuring proper mounting and alignment for optimal performance.
Estimated time: 30m
Tools needed:
Screwdriver, Wrench
Supplies needed:
Mounting screws, Nuts, Window
- Prepare the cutout
Make a rectangular cutout of size 6.69 x 4.69 inches (170 x 119 mm) where the window will be mounted.
- Remove protective paper
Remove the protective paper from both sides of the window to ensure a clean surface for installation.
- Install the window
Place the window into the frame within the stud perimeter and align it properly.
- Secure the frame
Position the frame and window against the enclosure with the studs protruding through the opening.
- Tighten the clamps
Assemble the clamps and nuts to the studs, align the window, and tighten all nuts to 15−20 in-lbs (1.7−2.3 Nm) of torque.
