nVent AFS12063-316 - Wall mounted, 1200x600x300, Hygienic encl., 1-door, with MP, stainless 316, IP66
nVent

AFS12063-316

UPC: 783510121044

Contact for Pricing

Overview

The nVent AFS12063-316 is a wall-mounted hygienic enclosure designed for demanding industrial environments. Constructed from AISI 316L pre-grained stainless steel, it offers superior corrosion resistance, making it ideal for food and beverage, pharmaceutical, and chemical processing applications. This enclosure boasts an IP66 rating, equivalent to NEMA Type 4X, 12, and 13, and an IK10 impact resistance rating, ensuring robust protection against dust, water, and physical impact. The integral sloping roof, angled between 8 and 20 degrees with a 10mm overhang, facilitates liquid and debris runoff, minimizing contamination risks and simplifying cleaning. The single-door design features a 1.5 mm thick door with a one-piece silicone gasket for reliable sealing. Internally, a 2 mm galvanized steel mounting plate, marked at 10 mm intervals, allows for easy equipment positioning and includes holes for cable fixing. The enclosure body and door are 1.5 mm thick. Delivered with the enclosure, door, mounting plate, metallic key, and mounting accessories.
  • Constructed from AISI 316L pre-grained stainless steel for exceptional corrosion resistance.
  • IP66, NEMA Type 4X, 12, 13, and IK10 ratings provide superior protection against environmental factors and impact.
  • Integral sloping roof (8-20 degrees) facilitates liquid runoff and simplifies cleaning.
  • 1.5 mm thick door with injected one-piece silicone gasket ensures reliable sealing.
  • Includes a 2 mm galvanized steel mounting plate with 10 mm interval markings for easy equipment placement.
  • Lock: Zamak double-bit 3 mm lock, with 90° movement. Stainless steel lock and other locks available on request.
  • Finish: 400 pre-grained stainless steel.
  • Door: Corner formed in one piece. Surface mounted with 130° opening. Concealed AISI 304 stainless steel hinges with captive pin. Can be mounted to give left or right hand opening (Machining is required). Sealing is ensured by an injected polyurethane gask
  • Delivery: Enclosure with door, mounting plate, metallic key and mounting accessories.
  • Cable access: No gland openings as standard.

Specifications

IP Rating
IP66
Material
Stainless 316
Material
AISI 316L pre-grained stainless steel
Mounting Type
Wall mounted
Nema Rating
Type 4X, 12, 13
Series
AFS
Series
nVent AFS
Size
1200x600x300
Size
1200x600x300 mm
Package Dimensions (L x W x H)
47.62 IN x 24 IN x 24.25 IN
Package Dimensions (L x W x H)
120.9548 cm x 60.96 cm x 61.595 cm
Package Weight (Imperial)
117.700 L
Package Weight (Metric)
53.389 kg
