Contact for Pricing
Overview
- Can be mounted at either top or bottom of door
- Can be installed on either left- or right-hinged doors
- Maintains UL/CSA Type 4, 4X, and 12 if properly installed in a HOFFMAN enclosure
- Includes stainless steel mounting screws and nylon washers
- Kit, including mounting hardware, constructed of Type 316 stainless steel
Specifications
Accessory Type | Door Accessories |
Application | Controls and Drives; Power Distribution; Corrosive Environments |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Color | Unpainted |
Finish | Brushed #3 |
Ip Rating | Type 4X |
Material | Stainless Steel 316 |
Material | Type 316 Stainless Steel |
Material | Stainless Steel 316L |
Material | Stainless Steel;Stainless Steel 316L |
Modification Services | Yes |
Mounting Type | Wall-mount |
Nema Rating | Type 4X |
Size | fits Type 12 Encl. in |
Thickness | 12 ga |
Thickness | 2.78 mm |
Thickness | 51.40mm (2.024") |
Type | Industrial Door Mounting and Locks |
Weight | 0.6 lb |
Works With | NEMA / IEC |
Package Dimensions (L x W x H) | 13.75 IN x 10.5 IN x 0.75 IN |
Package Dimensions (L x W x H) | 34.925 cm x 26.67 cm x 1.905 cm |
Package Weight (Imperial) | 0.600 L |
Package Weight (Metric) | 0.272 kg |
How to Install the Door Stop Kit ADSTOPKSS6
This guide provides step-by-step instructions for installing the Door Stop Kit ADSTOPKSS6 onto a Hoffman enclosure.
Estimated time: 30m
Tools needed:
Drill, Screwdriver, Wrench
Supplies needed:
M5 screws, M6 screws, Nylon washers, Lockwashers, M5 nuts, Shoulder bolt, Washer, Spring, Bushing
- Drill mounting holes
Drill two 6mm (.22 inch) diameter holes through the enclosure flange and two 6mm (.22 inch) diameter holes through the door at the specified locations.
- Attach mounting bracket
Bolt the mounting bracket to the enclosure body using M5 screws, nylon washers, lockwashers, and M5 nuts as shown in the installation diagram.
- Install guide bracket
Bolt the guide bracket to the door using the appropriate screws as indicated in the installation diagram.
- Attach stop arm
Bolt the stop arm to the guide bracket using the shoulder bolt as shown in the installation diagram.
- Secure stop arm
Fasten the other end of the stop arm to the mounting bracket using an M6 screw, washer, spring, and bushing as shown in the installation diagram.
- Verify installation
Check that all components are securely fastened and that the door stop functions correctly before energizing any circuits.
