nVent ADPX4C - External Data Pocket, Type 4 and 12, 12.00x18.00x3.25, Gray, Steel
nVent

ADPX4C

UPC: 783510155155

Documents & Media
Installation Instructions

Contact for Pricing

Overview

Enhance your industrial enclosure management with the nVent ADPX4C External Data Pocket. Designed for robust protection and convenient access, this Type 4 and 12 rated data pocket is an essential accessory for any critical control or automation system. Constructed from durable steel with a powder-coated gray finish, the ADPX4C is built to withstand harsh industrial environments, safeguarding vital documentation from dust, moisture, and physical damage. This nVent data pocket offers a secure and readily accessible location for essential system information, including schematics, operating manuals, maintenance logs, and safety procedures. By mounting externally to your enclosure, it eliminates the need to open the main enclosure door for routine document retrieval, thereby maintaining the integrity of the enclosure's environmental rating and preventing potential disruptions to sensitive electrical or electronic components. This is particularly crucial in applications where maintaining a controlled atmosphere or preventing ingress of contaminants is paramount. The generous dimensions of 12.00 inches in height, 18.00 inches in width, and 3.25 inches in depth provide ample space for a variety of document sizes and formats. The robust construction ensures longevity and reliability, making it a cost-effective solution for long-term operational efficiency. Installation is straightforward, allowing for quick integration into existing enclosure setups. Key benefits of the nVent ADPX4C External Data Pocket include: * **Enhanced Accessibility:** Provides instant access to critical documentation without compromising enclosure integrity. * **Superior Protection:** Type 4 and 12 rating ensures protection against dust, water, and other environmental contaminants. * **Durable Construction:** Made from heavy-duty steel for exceptional resilience in industrial settings. * **Increased Operational Efficiency:** Reduces downtime and simplifies maintenance by keeping essential documents readily available. * **Versatile Application:** Ideal for a wide range of industries including manufacturing, water/wastewater treatment, oil and gas, and power generation. As a trusted manufacturer in enclosure solutions, nVent delivers products that meet stringent industry standards. The ADPX4C, with its SKU ADPX4C, exemplifies this commitment to quality and functionality. Professionals across various sectors rely on nVent products for their dependable performance and innovative design. This data pocket is an indispensable tool for any facility prioritizing organized, safe, and efficient management of industrial control systems. Ensure your team has the information they need, when they need it, with the nVent ADPX4C External Data Pocket.
  • Available in mild steel or stainless steel to match the enclosure finish
  • Foam-in-place gasket to protect documentation from harsh environments
  • Hinged front for easy access to contents
  • Three sizes accommodate a wide variety of documents
  • Sloped top sheds liquids and prevents accumulation of extraneous material
  • Optional wing knob and keylock inserts available for additional security
  • Front of pocket hinges away from frame
  • Front of pocket hinges away from frame

Specifications

Accessory Type
Door Accessories
Application
Arc Flash Safety;Controls and Drives;Power Distribution
Application
Controls and Drives; Arc Flash Safety; Power Distribution
Color
Gray
Color
ANSI 61 paint;Gray
Color Code
ANSI 61
Finish
Powder Coated
Finish
ANSI 61 paint;Powder Coat
IP Rating
IP66
Material
Mild Steel
Material
Steel
Material
Mild Steel;Steel
Modification Services
Yes
Mounting Type
Exterior Mount
NEMA Rating
12 Indoor, dust-resistant
Nema Rating
Type 4 and 12
NEMA Rating
12
Product Family
InterSafe
Size
12.00x18.00x3.25
Size
12.00x18.00x3.25 in
Thickness
51.40mm (2.024")
Thickness
1.52 mm
Thickness
16 ga
Type
Industrial Door Mounting and Locks
Type Number
Type 4
Weight
15 lb
Works With
NEMA / IEC
Package Dimensions (L x W x H)
16 IN x 8 IN x 20 IN
Package Dimensions (L x W x H)
40.64 cm x 20.32 cm x 50.8 cm
Package Weight (Imperial)
15.000 L
Package Weight (Metric)
6.804 kg
