Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 16 Position Latching Cover
- Durable Black Thermoplastic Construction
- Secure Latching Mechanism
- Manufactured by TE Connectivity
- Ideal for Multi-Pole Systems
Specifications
Color | Black |
Feature | Type of accessory |
Material | Thermoplastic |
Poles | 16 |
Size | 16 Position |
S289JLN
2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Intermediate Spacer For Use With Nonmetallic Ducts
PE2V0636TC
Seals the top of a 6" PE2V for containment, improving airflow management and thermal efficiency. Top caps are reversable to be compatible with either 60% forward facing or 60% rear facing. Includes brushed pass through for sealed cable routing. It features a fixed 36" depth to match the depth of a 36" deep R4P36 or an AR4P set at a 30" or 36" depth. Designed to be used with AR4P or R4P top caps and PR2V/PE2V containment end panels to create a thermally contained solutionFrequently Asked Questions
What is the current rating per contact for this system?
The system is rated at 3 amperes per contact.
What is the operating temperature range for the housings?
The operating temperature range for black thermoplastic housings is -65°C to +105°C.
What is the centerline spacing for the AMPMODU system?
The AMPMODU system has a 0.100 [2.54] x 0.100 [2.54] centerline spacing.
What wire sizes are compatible with Mod IV contacts?
Mod IV contacts are compatible with 26-22 AWG [0.12-0.4 mm2] wire and 32-20 AWG [0.03-0.6 mm2] wire.
What are the available contact platings for this system?
Available platings include 0.00015 [0.00038] Gold, 0.00030 [0.00076] Gold, 0.00050 [0.00127] Gold, and Tin.
What is the insulation resistance of the system?
The insulation resistance is 5,000 megohms minimum initial.
What is the dielectric withstanding voltage?
The dielectric withstanding voltage is 750 V rms at sea level.
What is the post plating for standard unshrouded headers?
Standard unshrouded headers have posts plated with either 0.00030 [0.00076] gold or 0.00015 [0.00038] gold on the contact area.
Are there specific tools for applying contacts?
Yes, manual hand tools, pneumatic hand tools, and an Ocean Applicator are available for wire crimp and IDC applications.
What is the purpose of the anti-overstress stops in receptacle contacts?
Anti-overstress stops limit the deflection of the spring members to prevent excessive permanent deformation.
