Contact for Pricing
Overview
- 600mm x 48RU x 1070mm dimensions
- Includes single hinged perforated front door
- Features split perforated rear door for airflow
- Equipped with cage nut equipment rails
- Comes with PDU mounting bracket and casters
Specifications
Color | Black |
Depth | 42 in |
Depth | 1066.8 mm |
Finish | Powder Coating |
Material | Steel |
Width | 23.6 in |
Width | 599.44 mm |
Package Dimensions (L x W x H) | 43.5 IN x 23.5 IN x 79.6 IN |
Package Weight (Imperial) | 320 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
How to Install the FlexFusion XGL64812B Cabinet
This guide provides step-by-step instructions for the installation and setup of the FlexFusion XGL64812B cabinet, including mounting, leveling, and grounding procedures.
Estimated time: 1h
Tools needed:
13mm Socket Wrench, 15mm Socket Wrench, T25 Torx Driver, 6mm Hex Key
Supplies needed:
M10 Hex Head Screws, Shipping Hold Down Brackets, Grounding Lug or Grounding Bar, M5 Screws
- Remove Packaging Material
Remove all stretch wrap, protective cardboard, and plastic from the outside of the cabinet. Use at least two persons to carefully lift the cabinet off the pallet.
- Level the Cabinet
Ensure that the leveling legs are fully retracted. Move the cabinet into its final position and lower the leveling legs until the cabinet is fully supported. Adjust the legs to ensure the cabinet is level both front-to-back and side-to-side.
- Secure the Cabinet to the Floor
Attach the Shipping Hold Down Brackets to the cabinet using M10 screws. Ensure the cabinet is securely mounted to the floor to prevent tipping.
- Ground the Cabinet
Attach the Grounding Lug or Grounding Bar to the Common Bonding Network (CBN) at one of the grounding locations. Remove any masking tape covering the grounding lug location and use M5 screws to secure it, ensuring proper torque.
- Adjust Equipment Rail Spacing
Loosen the M8 Hex Head Bolts on the equipment rails, adjust them to the desired position, and ensure they are level. Retighten the bolts to the specified torque.
