Contact for Pricing
Overview
- Creates a barrier between adjacent FlexFusion cabinets without un-baying equipment.
- Features front and rear knock-outs for pass-thru cabling flexibility.
- Designed for 48RU x 1070mm deep black FlexFusion cabinets.
- Facilitates 'Day 2' cabinet additions and modifications with minimal disruption.
- Manufactured in the US for reliable infrastructure solutions.
Specifications
Color | Black |
Type | Side Panel Day 2 |
Width | 41.2 in |
Width | 1046.48 mm |
Package Dimensions (L x W x H) | 89.285 IN x 36.785 IN x 11.794 IN |
Package Weight (Imperial) | 54.3 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
How to Install the FLEXFUSION Day Two Side Panel & Brush Seal Pass Thru Kit
This guide provides step-by-step instructions for installing the FLEXFUSION Day Two Side Panel and Brush Seal Pass Thru Kit on your cabinet.
Estimated time: 45m
Tools needed:
T25 Torx driver, Tin Snips or Wire Cutters, Hand File
Supplies needed:
M5x0.8 x 12mm Button Head Torx Screws (Qty: 24), Grommets (Qty: 2), Brush Seals (Qty: 2)
- Prepare the Cabinet
Open the front door of the left-side cabinet to approximately 90° to access the installation area.
- Install the Front Panel
Slide the Day Two Front Panel through the gap between the two cabinet posts until the flanges contact the cabinet post. Secure the panel using M5x0.8 x 12mm Button Head Torx screws through the side of the cabinet post.
- Install the Rear Panel
Open the rear split doors to approximately 90°. Remove the left-side split door from the right-side cabinet and the right-side split door from the left-side cabinet. Slide the Rear Panel through the gap between the two cabinet posts and insert the tabs from the Rear Panel into the slots of the Front Panel. Secure the Rear Panel with M5x0.8 x 12mm Button Head Torx screws.
- Install the Brush Seal Pass Thru Kit
Using tin snips or wire cutters, cut the (14) tabs and remove the cut-out from the side panel. File down any burrs left behind. Insert grommets on the top and bottom of the cut-out, and insert brush seals on the left and right side of the cut-out.
