Panduit UTP6AX2VL - The TX6A 10Gig Cat 6A UTP Patch Cord is a 2-Foot, 0.250-inch (6.4mm) diameter, Violet cord constructed of 24 AWG, unshielded, twisted pair, solid, CM cable with high-performance modular plugs. Its solid foil tape limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Panduit

UTP6AX2VL

UPC: 613056771208

Documents & Media
BrochureTechnical BulletinTechnical DrawingFull Engineering DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 10

Multiplier: 1

*Contact for lower quantities*

Overview

The Panduit TX6A 10Gig Cat 6A UTP Patch Cord (SKU: UTP6AX2VL) delivers reliable 10 Gb/s data transmission with its 24 AWG solid unshielded twisted pair (UTP) construction. The 2-foot, 0.250-inch (6.4mm) diameter Violet cord features high-performance modular plugs and solid foil tape to limit alien crosstalk, ensuring consistent performance in high-density environments. The tangle-free latch design prevents snags during moves, adds, and changes, improving operational efficiency. Integrated RapidID barcodes enable quick port mapping via Panduit’s RapidID software, simplifying network management and reducing downtime. The CM-rated cable meets industry standards for general-purpose use in commercial and industrial applications. Ideal for data centers, enterprise networks, and structured cabling systems requiring high-speed, cost-effective connectivity.
  • 2-foot length with 0.250-inch (6.4mm) diameter Violet cord
  • 24 AWG solid unshielded twisted pair (UTP) construction
  • Solid foil tape limits alien crosstalk for 10 Gb/s transmission
  • Tangle-free latch prevents snags and ensures fast release
  • RapidID barcodes for simplified port mapping with Panduit software

Specifications

Color
Violet
Connection Type
Modular Plugs
Jacket Material
Polyvinyl Chloride (PVC)
Material
24 AWG solid unshielded twisted pair (UTP) CM cable
Outside Diameter
0.25 in
Outside Diameter
6.35 mm
Performance Level*
Category 6A
Series
TX6A 10Gig Cat 6A UTP Patch Cord
Size
2-Foot, 0.250-inch (6.4mm) diameter
Standard
Exceeds all ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA, meets ANSI/TIA-1096-A requirements (formerly FCC Part 68), meets IEC 60603-7, rated for 2500 cycles with IEEE 802.3af / 802.3at and 802.3bt type 3 and type 4, UL 1863, RoHS Compliant
Temperature Rating, Maximum
140 F
Temperature Rating, Maximum
60 C
Temperature Rating, Minimum
140 F
Temperature Rating, Minimum
60 C
Type
Patch Cord
Package Dimensions (L x W x H)
6 IN x 12 IN x 1.5 IN
Package Weight (Imperial)
0.102 lbs
