Panduit UTP6AX2 - The TX6A 10Gig Cat 6A UTP Patch Cord is a 2-Foot, 0.250-inch (6.4mm) diameter, Off-White cord constructed of 24 AWG, unshielded, twisted pair, solid, CM cable with high-performance modular plugs. Its solid foil tape limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Panduit

UTP6AX2

UPC: 613056769960

Documents & Media
BrochureTechnical BulletinTechnical DrawingFull Engineering DrawingSpecification SheetVideo Clip

Contact for Pricing

Minimum Qty: 10

Multiplier: 1

*Contact for lower quantities*

Overview

The Panduit UTP6AX2 is a 2-foot TX6A 10Gig Cat 6A UTP patch cord designed for high-speed network infrastructure. Constructed with 24 AWG solid unshielded twisted pair CM cable, this off-white cord features a 0.250-inch (6.4mm) diameter. Its design incorporates high-performance modular plugs and a solid foil tape to effectively limit alien crosstalk, ensuring reliable 10 Gb/s transmission speeds. The integrated tangle-free latch mechanism is engineered to prevent snags during installation and maintenance, while also facilitating a quick and easy release. This feature significantly streamlines moves, adds, and changes within network environments. Furthermore, the UTP6AX2 is enabled with Panduit's RapidID technology, featuring pre-installed barcodes. These barcodes simplify port mapping and network management when used in conjunction with RapidID software, enhancing operational efficiency and accuracy. Manufactured in the US, this patch cord meets stringent quality standards for critical network deployments.
  • 2-Foot TX6A 10Gig Cat 6A UTP Patch Cord
  • 24 AWG Solid Unshielded Twisted Pair CM Cable
  • 0.250-inch (6.4mm) Diameter, Off-White
  • Solid foil tape limits alien crosstalk for 10 Gb/s transmission
  • Tangle-free latch for snag prevention and fast release; RapidID enabled with pre-installed barcodes

Specifications

Application
(1) 10GBASE-T Ethernet (2) Data center I/O Consolidation (3) Data center server virtualization (4) Backbone aggregation (5) Parallel processing and high speed computing.
Jacket Material
Polyvinyl Chloride (PVC)
Outside Diameter
0.25 in
Outside Diameter
6.35 mm
Performance Level*
Category 6A
Standard
Exceeds all ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA standards for all frequencies from 1 to 500 MHz;IEC 60603-7;Meets ANSI/TIA-1096-A (formerly FCC Part 68);UL 1863 and CAN/CSA-C22.2 (UL File E129886), RoHS Compliant, Supports IEEE 802.3af/8
Temperature Rating, Maximum
140 F
Temperature Rating, Maximum
60 C
Temperature Rating, Minimum
140 F
Temperature Rating, Minimum
60 C
Type
Patch Cord
Package Dimensions (L x W x H)
6 IN x 12 IN x 1.5 IN
Package Weight (Imperial)
0.102 lbs
