Contact for Pricing
Minimum Qty: 10
Multiplier: 10
*Contact for lower quantities*
Overview
- 74.6mm (2.94in) width x 72.4mm (2.85in) height for ample cable routing
- 6.6ft (2m) length supports continuous duct runs without seams
- PPE+HIPS material with UL 94 V-0 flammability rating and UL Recognized for 203°F (95°C) continuous use
- Halogen-free construction verified per IEC 60754-2 for low corrosive gas emission
- Light gray color with DIN standard mounting holes for easy installation
- Base and cover packaged together for convenience and reduced ordering complexity
- Meets EN 45545-2 Hazard Level HL1 requirements for R23 exterior applications
Specifications
Adhesive Backed | DIN Standard Mounting Holes |
Application | (1) Type TNC Wiring Duct Routes, Protects, and Manages Electrical and Communication Cabling in Control Panels and Wire Routing Applications that Require Enhanced Material Performance for Fire Safety such as in Light Rail and Transit Systems, Commuter Buse |
Color | Light Gray |
Color | Gray |
Color | Grey |
Connection | DIN Standard Mounting Holes |
Length | NA In. |
Material | Polyphenylene Ether + High Impact Polystyrene (PPE + HIPS) |
Material Quality | PPE/HIPS |
Series | TNC |
Size | 2.94 x 2.85 IN |
Size | 74.6mm W x 72.4mm H x 6.6' length |
Slot Pitch | 0.39 in |
Slot Pitch | 9.906 mm |
Slot Style | Slotted |
Standard | RoHS Compliant, UL Recognized, CE Compliant, DIN 43659, DIN 5510-2 & DIN 54837 Compliant, EN45545-2 HL1, HL2 & HL3 Compliant, NFPA 120 Compliant, BABA Compliant |
Type | Wiring Duct Base with Cover |
Width | 2.94 in |
Width | 74.676 mm |
Package Dimensions (L x W x H) | 78 IN x 5.1 IN x 1.5 IN |
Package Weight (Imperial) | 3.02 lbs |
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
Frequently Asked Questions
What is the maximum operating temperature?
The maximum continuous operating temperature is 105°C (221°F).
What is the flammability rating of the material?
The material has a UL94 flammability rating of V-0.
Is the wiring duct halogen-free?
Yes, the wiring duct is made from low-smoke and halogen-free material.
What is the size of the TNC25X37LG2 wiring duct?
The TNC25X37LG2 wiring duct measures 25.0 mm x 37.0 mm (1.00 in x 1.50 in).
What is the minimum installation temperature?
The minimum installation temperature is -70°C (-94°F).
What standards does this product comply with?
The product complies with NFPA 1301, DIN 5510-23, and RoHS REACH.
What is the purpose of the divider wall?
The divider wall is used to create multiple channels within a single duct for separating cabling types.
What applications is the wiring duct suitable for?
It is suitable for control panels, data centers, and environments requiring enhanced fire safety.
How does the non-slip cover liner work?
The non-slip cover liner prevents sliding during shipment and installation.
What tools are recommended for installation?
Recommended tools include duct cutting tool (DCT) and nylon rivet installation tool (TNR).
