Contact for Pricing
Minimum Qty: 10
Multiplier: 1
*Contact for lower quantities*
Overview
- Category 5e shielded patch cord
- 15 meters in length
- Red color for easy identification
- Pan-Plug Shielded Modular Plugs on each end
- Reduces EMI and crosstalk for signal integrity
Specifications
Application | (1) Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), 1000BASE-T (Gigabit Ethernet)(2) 155 Mb/s ATM, 622 Mb/s ATM(3) Token ring 4/16(4) Voice/data systems(5) Voice over Internet Protocol (VoIP) |
Boot Type | Modular Plug |
Cable Type* | F/UTP |
Color | Red |
Color | International Gray |
Conductor Material | Copper |
Connection Type | Shielded Modular Plugs |
Jacket Material | LSZH Material |
Length | 49.21 In. |
Outside Diameter | 0.205 in |
Outside Diameter | 5.207 mm |
Performance Level* | Category 5e |
Plug Type | Modular Plug |
Series | Category 5e |
Size | 15 meters |
Standard | Exceeds all ISO 11801 Class D and ANSI/TIA-568.2-D Category 5e, meets ANSI/TIA-1096-A (formerly FCC Part 68), meets IEC 60603-7, UL 1863, Rated for 2500 cycles with IEEE 802.3af / 802.3at and 802.3bt type 3 and type 4, RoHS Compliant |
Temperature Rating, Maximum | 140 F |
Temperature Rating, Maximum | 60 C |
Temperature Rating, Minimum | 140 F |
Temperature Rating, Minimum | 60 C |
Type | Shielded Patch Cord |
Wire Size | 26 AWG |
Package Dimensions (L x W x H) | 14 IN x 10 IN x 1.5 IN |
Package Weight (Imperial) | 1.19 lbs |
TY29MX
High Performance Cable Tie, Black Color Nylon 6.6, Weather and Ultraviolet Resistant, Length of 762mm (30 Inches) for Bundle Diameter up to 229mm (9.02 Inches), Width of 6.9mm (0.27 Inch), Tensile Strength Rating of 534 Newtons (120 Pounds), Operating Temperature of -60 Degrees Celsius (-76 F) to 85 Degrees Celsius (185 F)
TYH27M
Cable Tie, Heat Stabilized Polyamide (Nylon 6.6) - Greenish Tint for Temperatures up to 105 Degrees Celsius (221 F) for Indoor Applications, Length of 343mm (13.5 Inches), Width of 6.9mm (0.27 Inch), Thickness of 1.5mm (0.06 Inch), Maximum Bundle Diameter 102mm (4.02 Inches), Tensile Strength Rating of 534 Newtons (120 Pounds)
A238
Two Gang Outlet Box, Volume 38 Cubic Inches, Length 3.844 Inches, Width 3.53 Inches, Depth 3.45 Inches, Number of Knockout 5, Knockout Size 1/2 Inch, 3/4 Inch, and 1 Inch, Color Blue, Material PVC
SVNDZ-P167GT
VNDZ Straight Connector with Strain Relief, PG Thread for IP66 Static Conduit - Thread PG 16, Fits to Conduit Size NW/Metric 17/20, Color Gray
Frequently Asked Questions
What is the maximum frequency supported by this patch cord?
It supports frequencies from 1 to 100 MHz, exceeding ISO 11801 Class D and ANSI/TIA-568.2-D standards.
What wiring schemes are compatible with this patch cord?
The patch cord is compatible with both T568A and T568B wiring schemes.
Is this product compliant with RoHS?
Yes, the patch cord is RoHS compliant.
What are the cable specifications for STPCH10MBYL?
The cable is 26 AWG shielded twisted pair stranded copper with a nominal diameter of 0.205 in.
What is the PoE compliance rating?
It is rated for 2500 cycles with IEEE 802.3af, 802.3at, and 802.3bt type 3 and type 4.
What lengths are available for this patch cord?
The patch cord is available in lengths from 1 to 40 meters in 1-meter increments.
How many mating cycles is the plug rated for?
The plug is rated for 2500 mating cycles.
What applications does this patch cord support?
It supports Ethernet, ATM, Token Ring, voice/data systems, and VoIP applications.
What is the flammability rating of the patch cord?
The patch cord has a CM/LSZH dual flammability rating.
What safety compliance standards does this product meet?
It meets ANSI/TIA-1096-A and IEC 60603-7 compliance standards.
