Contact for Pricing
Overview
- 79-inch tall, 42 RU 2-Post Open Frame Rack
- Constructed from lightweight extruded aluminum (6063-T6 alloy)
- UL listed for 1,000 lbs (453.6 kg) load capacity
- Accepts 19-inch wide equipment with #12-24 UNC tapped mounting holes
- RU markings on front and back for easy equipment placement
Specifications
Color | Black |
Depth | 15 in |
Depth | 381 mm |
Finish | Powder Coat |
Material | Aluminum |
Material | Extruded Aluminum |
Mounting Type | 2-Post Rack with #12-24 EIA universal mounting hole spacing |
Size | 79 inch tall, 3-inch deep channel, 42 RU |
Standard | UL 2416, EIA/ECA-310-E, RoHS Compliant |
Type | 2-Post Rack |
Width | 20.3 in |
Width | 515.62 mm |
Package Dimensions (L x W x H) | 80 IN x 6.5 IN x 4.5 IN |
Package Weight (Imperial) | 27.65 lbs |
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
PDCP2078
DataCom Enclosure Pkg, Bulletin DPVD (PROLINE® Voice and Data Package - PROLINE Voice and Data Package), Size/Dims: 2000x700x800mm, Material: Steel, Finish: Lt Gray
STP6X12MIG
This TX6A 10Gig Cat 6A STP Patch Cord is a 12-Meter, Int'l Grey cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable and with high-performance modular plugs. Its tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. The slender strain relief boot provides easy access in high-density applications. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What are the dimensions of the R2P79 product?
The R2P79 product has a height of 84 in, width options of 6, 8, 10, or 12 in, and a depth of 26.8 in.
What safety standards does the R2P79 meet?
The R2P79 meets UL 2416 and CSA C22.2 safety standards.
What is the depth of the R2P79 cable manager?
The R2P79 cable manager has a depth of 26.8 in.
Is the R2P79 suitable for high-density environments?
Yes, the R2P79 is designed for high-density cabling environments, maximizing space efficiency.
What is the height of the R2P79 cable manager?
The R2P79 cable manager has a height of 84 in.
What is the maximum cable capacity?
The PatchRunner 2 offers up to 45% more usable capacity compared to the previous model, accommodating high-density cabling.
What is the installation requirement for the R2P79?
The R2P79 can be mounted on standard 19 in. EIA racks, utilizing zero RU space for accessories.
How does the bend radius control work?
The molded fingers of the R2P79 provide integral bend radius control, ensuring proper cable management and network performance.
What accessories are compatible with the R2P79?
Compatible accessories include patch panels, strain relief bars, blanking panels, and various cable management tools.
What type of door does the R2P79 have?
The R2P79 features a dual hinged, push-to-close door design for easy operation.
How to Install the R2P79 Rack Assembly
This guide provides step-by-step instructions for assembling and mounting the R2P79 rack securely.
Estimated time: 1h
Tools needed:
Screwdriver, Carpenter square, Torque wrench
Supplies needed:
3/8x1” bolts, 3/8” nuts, 3/8” paint piercing washers, Antioxidant paste, Mounting hardware for floor
- Prepare surfaces
Apply antioxidant paste to painted surfaces that the 3/8 paint piercing washers will contact to prevent corrosion.
- Install top angles
Attach the top angles to the upright channels using (2) 3/8x1” bolts, (2) 3/8” nuts, and (4) 3/8” paint piercing washers per angle. Finger tighten only.
- Install base angles
Secure the base angles to the vertical upright channels using (4) 3/8x1” bolts, (4) 3/8” nuts, and (8) 3/8” paint piercing washers per angle. Finger tighten only.
- Stand the rack upright
Carefully stand the rack upright and use a carpenter square to ensure the upright channels are squared with the base.
- Tighten bolts
Completely tighten all bolts to at least 14 ft-lbs (19.0 N-m) using a torque wrench.
- Mount rack to the floor
Securely mount the rack to the floor using appropriate hardware based on the floor construction (concrete, raised floor, or wood).
- Verify weight distribution
Ensure that the weight load of the rack does not exceed 1,000 pounds and is evenly distributed, with heavier components at the bottom.
