Contact for Pricing
Overview
- 30 x C13 outlets and 6 x C19 outlets for high-density power distribution
- 16 Amp, 400 Volt, three-phase operation for demanding applications
- IEC 60309 3P+N+E 6h 16A (IP44) input plug for secure industrial connectivity
- Monitored and switched functionality for intelligent power management and remote control
- Durable black finish with a 10-foot (3m) power cord for flexible installation
Specifications
Package Dimensions (L x W x H) | 78 IN x 8.2 IN x 4.6 IN |
Package Dimensions (L x W x H) | 198.12 cm x 20.828 cm x 11.684 cm |
Package Weight (Imperial) | 17.2000 L |
Package Weight (Metric) | 7.8019 kg |
UTP6AL1MBU
The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
CPP24FMWBLY
The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.
ST4803PDGM
Surge-Trap® Surge Protective Device is a no-fuse surge suppressor. The Surge-Trap is a UL 1449 Third Edition compliant modular style surge protective device that is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator and a small foot print. A remote indicator option provides status to critical control circuit. The Surge-Trap provides advanced overvoltage protection utilizing Mersen's patented TPMOV® technology without additional protection devices. 480 Volts 3P Delta system type without N-G mode, with microswitch .
CUSTOMDIN
DIN rail is a universal mounting option for electrical and industrial control products such as circuit breakers electrical supplies terminal blocks and more. The rail system is used to stabilize a wide variety of devices and products. Ordering pre-cut DIN rail helps increase productivity and decrease jobsite clutter. On-site Flexibility Streamline custom cuts DIN rail to any length so it is ready to use when it arrives on the jobsite. Additionally DIN rail can be easily removed if relocation is necessary. Features of Custom DIN Rail from Streamline - All cut DIN rail from Streamline is galvanized steel made to eliminate rusting. Streamline ensures that all custom DIN rail orders are: De-burred Custom Length Any quantity 1-1000+ Quick turnaround (typically 2 weeks or less from receipt of order) This mechanical support structure is a must for all electrical parts solutions big or small. DIN rail allows for mounting hardware easily and quickly. These durable and versatile rails make the perfect solution for all mounting applications. Save space time and money with these cost-effective mounting solutions. Order your custom cut DIN rail today!
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What is the voltage rating of this Panduit PDU?
The Panduit G6 Monitored Switched PDU has a voltage rating of 400 V.
How many C13 and C19 outlets does this PDU have?
This PDU features 30 C13 outlets and 6 C19 outlets.
What type of input plug does the PDU use?
The PDU uses an IEC 60309 3P+N+E 6h 16A input plug.
What is the IP rating of this Panduit PDU?
The Panduit G6 Monitored Switched PDU has an IP44 rating.
What is the current rating for this PDU?
This PDU is rated for 16 amps.
What is the color of the Panduit G6 Monitored Switched PDU?
The Panduit G6 Monitored Switched PDU is black.
What is the power cord length for this PDU?
The power cord for this PDU is 10 feet (3 meters) long.
How to Install and Configure Panduit G6 Power Distribution Units (PDUs)
This guide provides step-by-step instructions for installing Panduit G6 Metered, Switched, and Metered & Switched PDUs into a datacenter rack, including mounting, grounding, connecting to power, and initial configuration for universal input models.
Estimated time: 1h
Tools needed:
Phillips screwdriver, Torx screwdriver
Supplies needed:
Mounting buttons, Tie wraps, Ground bonding cable, Input cord plug (for Universal Input PDUs)
- Install Mounting Hardware on the PDU
Determine the desired PDU orientation (outlets facing center, back, or front of the rack). Align and install the mounting buttons into the appropriate screw holes on the PDU: either on the face opposite the outlets (for center-facing) or on the sides of the PDU (for back/front-facing). Ensure the buttons are securely fastened. Use only the hardware provided for installation.
- Mount the PDU in the Rack
Carefully insert the installed mounting buttons on the PDU into the keyhole slots on the PDU mounting bracket within the rack. Ensure the PDU is firmly seated and stable. For Universal Input PDUs, be aware that if the input cord is at the top, the top three RUs might be obstructed at the back by the input cord plug.
- Connect the Ground Bonding Cable
Locate the external ground bonding point on the PDU chassis (on the outlet surface for most models, or circuit breaker surface for dual-sided models). Connect a ground bonding cable from this point to a known earthed reference terminal in the building, a grounding strip, or a grounding bus bar in the rack. Ensure the connection is secure to establish a reliable grounded (earthed) connection. This is essential to reduce the risk of electric shock due to high leakage currents. Refer to the document for minimum bonding conductor requirements based on PDU amperage.
- Attach the Input Cord (for Universal Input PDUs)
If installing a Universal Input PDU, open the input cord connector latches on the PDU. Insert the appropriate input cord plug into the connector. Close the input cord connector latches on the PDU to securely lock the input cord into place.
- Connect the PDU to a Power Source
WARNING: To reduce the risk of fire, electric shock, and equipment damage, ensure the feed circuit breaker for the power source is in the 'Off' position before connecting. Verify that all individual circuit breakers on the PDU itself are set to 'On'. Connect the PDU's input power cord to an appropriately rated, grounded (earthed) branch circuit. Refer to the label on the PDU for its input ratings. Ensure the connected devices are capable of operating from the same line voltage. Do not overload the PDU. Once connected, turn the feed circuit breaker 'On'. The PDU's OLED screen will display a status bar during startup, then the Main Menu.
- Configure Universal Input PDU Input Type (Web Interface)
Access the PDU's Web interface (refer to the User Manual for connection instructions). Navigate to the 'System Management' page under 'Settings'. Select 'Set Input Cord' under 'Actions'. From the dropdown menu, select the correct cord type that matches your connected input cord. NOTE: Selecting an incorrect type may lead to inaccurate metering and incorrect power rating display. Click 'Save'; the PDU will then reset.
